AT-GS950/48PS Switch Web Interface User’s Guide
185
Queue Scheduling Algorithm
To change the scheduling algorithm for the egress queues, perform the
following procedure.
1. From the main menu on the left side of the page, select Bridge.
The Bridge folder expands.
2. From the Bridge folder, select QoS.
The QoS folder expands.
3. From the QoS folder, select Scheduling Algorithm.
The Scheduling Algorithm Page page is shown in Figure 62.
Figure 62. Scheduling Algorithm Page
4. In the Scheduling Algorithm list, select the algorithm, one of the
following:
Strict Priority - The port transmits all packets out of higher priority
queues before transmitting any from the lower priority queues.
WRR (Weighted RoundRobin) - The port transmits a set number
of packets from each queue, in a round robin fashion, so that each
has a chance to transmit traffic. See Table 5 on page 179 for
number of packets versus the port egress queue.
5. Click Apply.
6. From the main menu on the left side of the page, select Save
Configuration to Flash to permanently save your changes.
