Chapter 13
Virtual LANs
This chapter contains a description of Virtual Local Area Networks
(VLANs) and the procedures for creating, modifying, and deleting both
port-based and tagged VLANs. This chapter contains the following
sections:
“VLAN Overview” on page 150
“Assign Ports to a VLAN Mode” on page 155
“Tagged VLAN Configuration” on page 157
“Port-Based VLAN Configuration” on page 164
“Modify a Port-Based VLAN” on page 165
“Delete a Port-Based VLAN” on page 165
Note
The Voice VLAN feature is not covered in this section. For more
information, see “Voice VLAN” on page 257.
Note
To permanently save your new settings or any changes to the
configuration file, select Save Configuration to Flash from the main
menu on the left side of the page.
