AlliedWare Plus Version 2.1.2 Management Software Web Browser User’s Guide

Assigning a Destination Port

The destination port is the source port where the information from the

mirror transmit and mirror receive ports is copied. You must assign the

destination port before the mirror transmit and mirror receive ports. Also,

you can only assign one destination port to the switch.

To assign a destination port, do the following:

1. Select the Switching tab.

The Switching tab is displayed. See Figure 19 on page 58.

2. From the Switching tab, select Port.

The Port tab is displayed.

3. From the Port tab, select Mirroring.

The Port Mirroring List page is displayed. See Figure 28 on page 83.

4. Select the pull-down menu next to the Destination Port field at the top

of the page.

5. Click on the port that you want to designate as the destination port.

You can only assign one destination port to a switch.

6. Click Apply.

The Edit option is removed from the port. This indicates the

destination port for the switch.

7. Click SAVE
