Chapter 3: Basic Switch Parameters

Setting a Remote Log Server

You can use the AlliedWare Plus Web browser interface to assign the

switch to a remote log server which is part of the Syslog feature. However,

you must use the CLI to view or clear the event log. For information about

the CLI, see the SysLog chapters in the AlliedWare Plus Management

Software Command Line Interface User’s Guide.

To activate remote logging on the switch, do the following:

1. Select the System tab.

The System Settings tab is displayed. See Figure 6 on page 33.

2. From the System Settings tab, select Services.

The System Services page is displayed. See Figure 10 on page 39.

3. Configure the following parameters as necessary:

 Remote Log— Enables the switch to send status and error

messages to a remote log server. This parameter is optional.

 Server IP Address— Specifies the IP address of the remote log

server. This field is mandatory if you selected the Remote Log field

above. You can enter the IP address in the IPv4 format:

xxx.xxx.xxx.xxx.

where each x is a decimal number from 0 to 255. The numbers are

separated by periods.

4. Click Apply.

5. Click S

AVE to save your changes on the switch.
