User's Manual

AlliedWare Plus Version 2.1.2 Management Software Web Browser User’s Guide
205
7. Change the fields as needed.
You must define the Id and Country fields. The remaining fields are
optional.
The fields are listed in step 5. Each field can contain up to 255
characters.
Note
The Country field must contain two uppercase characters, for
example, “US.”
8. Click Apply.
Creating a
Coordinate
Location
To create an LLDP Coordinate Location, do the following:
1. Select the Discovery & Monitoring tab.
The Discovery & Monitoring tab is displayed. See Figure 68 on page
201.
2. From the Discovery & Monitoring tab, select LLDP.
The LLDP tab appears on the right.
3. From the LLDP tab, select Locations.
The Locations tab is displayed. See Figure 69 on page 202.
4. From the Location tab, select Coordinates.
The LLDP Coordinate Location page is displayed. See Figure 72.
Figure 72. LLDP Coordinate Location Page
5. From the LLDP Coordinate Location page, click Add
.
