Hardware Reference 7
C613-03026-00 REV F
AT-A40/SC 1-port 100BASE-FX Multimode Fibre
(SC connector)
Figure 4: AT-A40-FX (SC) Uplink module.
AT-A40/MT 1-port 100BASE-FX Multimode Fibre
(MT-RJ connector)
Figure 5: AT-A40-FX (MT-RJ) Uplink module
AT-A41/SC 1-port 100BASE-FX Singlemode Fibre
(SC connector)
Figure 6: AT-A41-FX (SC) Uplink module.
AT-A40 / FX
100BASE-FX / SC
FULL DUP
100M LINK FAULT
ACTIVITY
COL
HALF DUP
CLASS 1
LASER PRODUCT
DO NOT STARE
INTO BEAM
RXTX
AT-A40 / FX
100BASE-FX / MT-RJ
FULL DUP
100M LINK FAULT
ACTIVITY
COL
HALF DUP
CLASS 1
LASER PRODUCT
DO NOT STARE
INTO BEAM
AT-A41 / FX
100BASE-FX / SC
FULL DUP
100M LINK FAULT
ACTIVITY
COL
HALF DUP
CLASS 1
LASER PRODUCT
DO NOT STARE
INTO BEAM
RXTX
