Hardware Reference 5
C613-03026-00 REV F
Information on other expansion options for the AR800 and Rapier Series:
■
The Network Service Module Quick Install Guide, which outlines the
procedure for installing an NSM; and the Network Service Module Hardware
Reference, which provides detailed information on NSMs.
■
The Port Interface Card Quick Install Guide, which outlines the procedure for
installing PICs; and the Port Interface Card Hardware Reference, which
provides detailed information on PICs.
All of these documents can be found on the Documentation and Tools CD-
ROM bundled with each Switch or Switching Router, or at
www.alliedtelesyn.co.nz/support/support.html.
Compatible Switch Units
This section lists all uplink module models, and indicates which switches each
model can be installed in.
• AT-A35/SX: All Rapier Switches, Rapier i switches, and AR800
Modular Switching Routers
• AT-A35/LX: All Rapier Switches, Rapier i switches, and AR800
Modular Switching Routers
• AT-A39/T: All Rapier Switches, Rapier i switches, and AR800 Modular
Switching Routers
• AT-A40/SC: Rapier G6 and G6F switches and all Rapier i switches
• AT-A40/MT: Rapier G6 and G6F switches and all Rapier i switches
• AT-A41/SC: Rapier G6 and G6F switches and all Rapier i switches
• AT-A41/MT: Rapier G6 and G6F switches and all Rapier i switches
Hardware Description
This section provides information on the hardware features of all Uplink
Module models.
Uplink Module Overview
Uplink Modules allow extra ports and port types to be added to the switch.
Uplink Modules also increase switching capacity by allowing switches to be
linked.
AT-82xx Expansion Modules are not compatible with AR800 Series Modular
Switching Routers or Rapier Switches. Attempting to install an AT-82xx
Expansion Module into an AR800 Series Modular Switching Router or Rapier
Switch may damage the Switch Unit and Expansion Module. If you are unsure
of a Module’s compatibility, before installing it, contact an authorised Allied
Telesyn distributor or reseller.
