Specifications

14 Uplink Module
C613-03026-00 REV F
Port, Connector, and Cable Combinations
1. Refer to the IEEE 802.3 Standards for further cable information.
2. Assumes a fibre optic cable rating of 500 Mhz/Km. (Maximum cable length is 500m at a cable rating
of 400 Mhz/Km.)
3. Assumes a fibre optic cable rating of 200 Mhz/Km. (Maximum cable length is 220m at a cable rating
of160 Mhz/Km.)
4. Early versions of the AT-A39/T operate at 1000 Mbps only. 10/100/1000 Mbps operation is available
only if the AT-A39/T Uplink Module is installed in a Rapier G6, Rapier G6F or Rapier i model,
otherwise operation is fixed at 1000 Mbps.
This section lists the recommended cable types and maximum cable lengths for each uplink module
model.
Table 12: Port, Connector, and cable Combinations.
Model Port Type Connector
Type
Cable Type
1
Maximum Cable
Length
AT-A35/SX 1000BASE-SX SC 50/125 micron multimode
fibre
62.5/125 micron
multimode fibre
550m (1,804ft)
2
275m (902ft)
3
AT-A35/LX 1000BASE-LX SC 9/125 micron singlemode
fibre
50/125 or 62.5/125
micron multimode fibre
3km (1.8mi)
Increasing to 10km (6mi)
if linking two 1000BASE-
LX models
550m (1804ft)
2
AT-A39/T 10100/1000BASE-T
4
RJ-45 CAT5
CAT5E
100 to 150m
(328 to 492ft)
200m (656ft)
AT-A40/SC 100BASE-FX
(Multimode fibre, 1300nM)
SC 50/125 or 62.5/125
micron multimode fibre
2km
AT-A40/MT 100BASE-FX
(Multimode fibre, 1300nM)
MT-RJ 50/125 or 62.5/125
micron multimode fibre
2km
AT-A41/SC 100BASE-FX
(Singlemode fibre, 1300nM)
SC 9/125 micron singlemode
fibre
15km
AT-A41/MT 100BASE-FX
(Singlemode fibre, 1300nM)
MT-RJ 9/125 micron singlemode
fibre
15km
