x600 Layer 3 Gigabit Ethernet Switch Installation Guide
107
Table 18 lists the RPS 17-pin D-combo port and connector pinout
definitions.
Table 18. AT-RPS3104 17-Pin Connector Pinout Definitions
Pin Definition
A1 48V Return
A2 Return
148V
248V RS+
3 Redundant Power Supply (RPS) present
4 RPS_EN
512V RS+
612V
73.3V
848V
948V
10 48V RS-
11 RPS GOOD
12 3.3V RS-
13 3.3V RS+
14 3.3V
15 3.3V
