CG-WLBARGMO MISO Wireless broadband Router User Manual
Contents WLBARGMO Manual 1. Product Introduction...................................................................................................3 1.1 Package Contents............................................................................................3 1.2 Features...............................................................................................................3 1.3 Hardware Introduction...............................................................................4 2.
Contents WLBARGMO Manual ...................................................................................................... 30 ..............................................................30 .........................................................33 .............................................................34 ..........................................................................
1 Product Introduction WLBARGMO Manual Corega WLBARGMO is a MISO wireless broadband Router with IEEE802.11g wireless access point standard. Its MIMO XR technique can improve transmit speed and coverage area. The maximum transmit length is up to 450m and the coverage area can be six times more than general 802.11g products. It also has 3 antennas which can improve transmit quality. Moreover, WLBARGMO supports security settings, such as WEP, WPA/WPA2-PSK, and 802.1x.
WLBARGMO Manual 1.3 Hardware Introduction 2 6 1 3 4 5 9 8 10 7 11 1. Initial Button Press this button it will reset to default setting 2. WLAN LED (Green) ON:Connected 3. Power LED (Green) Indicate power status 4.Status LED (Red) Blink:Working normal ON:Firmware upgrade 5. WAN LED (Green) ON:Connected Blink:Transmitting or receiving data 6. Speed LED (Green) ON:100Mbps Off:10Mbps 4 7. Link LED (Green) ON:Connected Blink:Transmitting or receiving data 8. Detachable Antenna Connector 9.
2 Product Installation WLBARGMO Manual 2.1 Hardware Installation Following the steps below to set up WLBARGMO and the connection. (1) Insert the cable connector into the Network Adapter embeded in PC, and insert the other side into one of LAN ports (1~4) of the Router. (2) Insert the connect into the WAN port of the Router and insert the other side into the modem. (3) Connect the Power Adapter, and plug in the AC power. WAN LAN 2.
PC Setting WLBARGMO Manual 3 3.1 TCP/IP Configuration The following steps and screenshots maybe dissimilar in different operating systems. This manual takes Windows XP/2000, 95/98/ME, and Mac O/S as examples: 3.1.1 Windows XP O/S (1) Enter [Control Panel] -> click [Network Connection] -> right click and select [Open]. (2) Click [Local Area Connection] and right click and select [Properties].
WLBARGMO Manual (3) Click [General] -> click [Internet Protocol (TCP/IP), and click [Properties]. (4) Click [General], select [Obtain an IP Address Automatically], and [Obtain DNS Server address automatically], and press [Advance].
WLBARGMO Manual (5) Click [DNS] tab, unselect [Register this connection’s address in DNS], and press [OK]. (6) Go back to [Internet Protocol TCP/IP] and press [OK]. (7) Press [OK] to close [Local Area Connection Properties]. 3.1.2 Windows 2000 O/S (1) Go to [My Computer], and enter [Control Panel], click open [Network and Dial Up Connections].
WLBARGMO Manual (2) Right click [Local Area Connection], and select [Properties] *Note: Please check if TCP/IP had been installed in the [Local Area Connection]. (3) Click [Internet protocol (TCP/IP)] and click [Properties].
WLBARGMO Manual (4) Select [Obtain an IP address automatically], and [Obtain DNS server address automatically]. And click [Advance]. (5) Click [DNS] tab in [Advance TCP/IP setting] page, and unselect [Register this connection’s DNS address, and press [OK].
WLBARGMO Manual 3.1.3 Windows 98/95/ME O/S The configurations in all Windows 98/95/ME are the same, and this manual takes Windows 98 as an example. (1) Enter [Control Panel], and double click [Network]. (2) Click [Configuration] tab, and select [TCP/IP], click [Properties]. (3) Select [IP Address], and select [Obtain IP address automatically. Press [OK].
WLBARGMO Manual (4) Click [Gateway] tab, remove all the gateways, and press [OK] to close the window. (5) Go to [Network] and press [OK] to close the page. (6) The [Restart the windows] screen will pop-up, press [OK] to restart the PC. If the PC is not shown this message, restart the PC manually. 3.1.4 Mac OS 8.x~9.x O/S (1) Open the [TCP/IP] configuration from [Control Panel]. (2) Select [Ethernet Network] in the [connection methods]; select [DHCP server] in [Configuration], and close this page. 3.1.
WLBARGMO Manual 3.2 Browser Configuration 3.2.1 Windows O/S The following examples are for Windows XP O/S, skip this chapter if you are using Windows 2000/98/ME. (1) Open Internet Explorer (IE 6.0), select [Tools] menu and click [Internet Options]. If a [Dial-up Connection] window is pop-up, close it, and do not connect to the Internet now. (2) Click [Connections] tab -> select [Never dial a connection] -> click [LAN Settings].
WLBARGMO Manual (3) Unselect all three options in the [Local Area Network LAN Setting]. (4) Press [OK] in the [Internet Options]. 3.2.2 Mac O/S (1) Open Internet Explorer (IE 5.0) Go to [Edit] in the menu bar, select [Internet Explorer Preferences]. (2) Select [Proxies] options in [Network] on the left-side configuration items. (3) Do not select [Web Proxy], press [OK].
4 Network Configuration WLBARGMO Manual 4.1 Quick Network Configuration Basic configuration is required before connection your computer to the internet via WLBARGMO. The connection methods may be differed by your contract to the ISP. Please reconfirm your connection conditions with your ISP prior to configure this router. The configuration procedures are as follow: *Note: Anti-virus or Firewall software may prevent this router from being set-up properly.
WLBARGMO Manual (5) Click [Quick Installation Setting]. (6) When seeing this screen shot, click on [Next]. (7) Select your connection type. Please make sure that your ADSL connection type is correct as you enter; the correct information can be obtained from the documents given by your ISP. If not, consult with your ISP before setting.
WLBARGMO Manual 4.1.1 Auto obtain IP (DHCP) (1) If you are subscribing to auto obtain IP service ( or DHCP Dynamic IP) from your ISP, such as Cable Modem that obtain an IP automatically for connection, please select [Auto obtain IP(DHCP)]. Click on [Next]. (2) Press [MAC address clone] to obtain the Ethernet card’s MAC address. Then press [Next].
WLBARGMO Manual (3) Click on [Save] to perform connection tests. (4) Within seconds, the result of the connection test will be appeared in the dialogue box to indicate the connection status. When [Connection ok] appears, click on [Close]. (5) Open the web browser (IE 6.0), and test with any website for testing the connection. * Note: if the connection to the website fails. Restart your Cable Modem, and check the installation of CG-WLBARGMO properly, such as the LAN/WAN connections.
WLBARGMO Manual 4.1.2 Fixed IP (1) If you are subscribing Fixed IP connection from your ISP, then select [Fixed IP], and click on [Next]. (2) Enter the network setting provided by your ISP. Then click on [Next].
WLBARGMO Manual (3) Click on [Save] to perform connection tests. (4) Within seconds, the result of the connection test will be appeared in the dialogue box to indicate the connection status. When [Connection OK] appears, click on [Close].
WLBARGMO Manual (5) Open the web browser (IE 6.0), and test with any website for testing the connection. *Note: If the connection to the website fails. Please make sure the data you entered are correct , or any mistake occured in the process of the installation, such as the LAN/WAN connections. After verifying that, repeat these setps in the section. 4.1.
WLBARGMO Manual (3) Click on [Save] to perform connection tests. (4) Within seconds, the result of the connection test will be appeared in the dialogue box to indicate the connection status. When [Connection OK] appears, click on [Close].
WLBARGMO Manual (5) Open the web browser (IE 6.0), and test with any website for testing the connection. *Note: If the connection to the website fails. Please make sure the data you entered are correct , or any mistake occured in the process of the installation, such as the LAN/WAN connections. After verifying that, repeat these setps in the section. 4.2 Establishing the Wireless Internet Connection So far, you should be able to connect to the Internet wirelessly.
WLBARGMO Manual (2) Go [Control Panel] -> [Network connection] again ->Right click [Wireless network connection] ,select [Available wireless network connection], choose one available network e.g. ) corega , and click [Connect]. (3) Connection status will appear in the bottom right of the screen.
WLBARGMO Manual (1) Go [Control Panel], double click on [Network connection], right click on [Wireless Networks Connection], select [properties], click on [Wireless Network] tab, select [Use Windows to configure my wireless networks setting] , and press [OK]. (2) Go [Control Panel] -> [Network connection] again -> right click [Wireless network connection] , select [Available wireless network connection], e.g. ) corega , and click [Connect].
WLBARGMO Manual (3) Connection status will appear in the bottom right of the screen. *Note: The wireless connection has been established now. Please go to corega’s website at http://www.corega-asia.com to check the connection to the Internet.
5 Wireless Security Configuration WLBARGMO Manual To prevent from unlawful access to your network, you are recommended to perform wireless security setting. Type [192.168.1.1] in the browser’s address bar, press [Enter]. Enter the function menu, ad click on [802.11g/b Security setting] item. And select WEP or WPA setting. 5.1 WEP Setting In order to prevent your information from being hacked, it is recommended to use WEP encryption when using wireless connection.
WLBARGMO Manual 5.2 WPA Setting WPA is encrypted by a periodic update, making it more difficult to be hacked. Home users and company users are recommended to use and respectively. (1) Select [WPA2-PSK] or [WPA/WPA2-PSK] in the column of [Authentication] (Recommended). a. [WPA2-PSK]: The 2nd generation encryption technology performs stricter protection than ever. Before selection, please check the function availability of your network adapter, or select b. b.
WLBARGMO Manual (1) Select [WPA2-EAP] or [WPA/WPA2-EAP](Recommended). in the column of [Authentication] a. [WPA2-EAP]: The 2nd generation encryption skill performs stricter protection than before. Before selection, please check the function availability of your network adapter, or select b. b. [WPA/WPA2-EAP]: If selected, encryption type will be defined automatically according to the corresponding wireless network adapter. (2) Select [Cipher Type] (Recommended to keep the default).
Function Introduction WLBARGMO Manual 6 The chapter will briefly introduce all functions of this product, and spell them out. Log in the management program and the below interface will appear. 6.1 Features Mode Select and switch to Router(wireless broadband router) or AP(Acess point) mode. *Note:When switch to AP mode, the product will stop sending IP, the WAN port will not be function. The LAN port will also turn to general Hub function. Therefore, we suggest user to use the default setting.
WLBARGMO Manual A. For [PPPoE]: Username Password Confirm password Connection type Authentication and MTU value DNS Server Please enter username, given by your ISP. Please enter password, given by your ISP. Please type your password again. [Auto Reconnect]: always on line (recommended). [On Demand]: connect when accessing to Internet. [manual connection]: manually connecting to internet. Maximum Transmission Unit. when [Auto Reconnect] is disable, MTU can be edited. Default setting: 1454 Byte.
WLBARGMO Manual B.For auto obtain IP (DHCP) : 32 Type Press [MAC address clone] to obtain the Ethernet card's MAC address. Host name Please refer to your ISP internet service information, add/edit [Host name]. MTU value Maximum Transmission Unit.deafault setting:1500 Byte.
WLBARGMO Manual C. For fixed IP WAN IP address Subnet mask Default gateway MTU DNS server Multi-NAT Please refer to your ISP internet service information. Maximum Transmission Unit. Deafault setting :1500 Byte.
WLBARGMO Manual (1) select enable dynamic DNS services. (2) Select one DDNS Provider. (3) enter login name. (4) enter login password. (5) Domain name. (6) Click [Save]. *Note: Corega does not provide DDNS service. Please register on one DDNS provider web site before you setup this function. VPN PPTP pass through VPN pass-through function enable/disable. VPN IPSec pass through VPN pass-through function enable/disable.
WLBARGMO Manual (1) Select [Enable] to enable DHCP server function. Default is [enable]. (2) Enter DHCP servers start IP and end IP. (3) Then click on save button to save the setting. the following table display the current connected users information, you can add/edit/delete users data. *Add a pc data : click on [add] to add a new user data. (1) Enter the pc name and select PC obtain IP method. (2) Configure the MAC address data of PC.
WLBARGMO Manual 36 ESSID ESSID is a name that makes wireless adapter identify this Router . The default ESSID is [corega]. Mode • 802.11b/g: auto connect in either 802.11b or 802.11g. • 802.11g: connect in 802.11g mode. Channel When there is interruption, other channels can be selected. TX Burst Enable/Disable frame burst function. When it is checked, transmit throughput will be improved. Only work with corega WLCBGMO or WLUSB2GO.
WLBARGMO Manual This section contains WEP,WAP-PSK, WPA2-PSK, WPA-EAP and WPA2-EAP encryption setting, please refer to Chapter 5 to get detail information. Wireless to wireless connection Configure wireless communication between clients. [Enable]/[Disable]: enable or disable wireless communication between clients. Wireless to wire connection Configure wireless and wired communication between clients.
WLBARGMO Manual Configuring firewall and no response to WAN Ping requests. This function can limit or control some certain networking services: (1) Enter the range of limited IP address. (2) Select one of limit/stop networking services. (3) Select one of protocol. (4) Enter the range of limited port number. (5) Select one of the time schedule limitations.
WLBARGMO Manual This function can forbid users to access certain website on the Internet: (1)Enter the forbidden URL or keywords (2) Then click [save] to complete the configuration. All the forbidden data will be displayed in the table below. Virtual server is an appointed port opened by the PC in connection with the product, allowing other users connecting up via WAN. Open servers or special online games can take advantage of this function.
WLBARGMO Manual If the online game’s port range is unknown, or its parameter is different every login, DMZ function is recommended. While this function starts, select the users, being allowed to connect with, then click [Save]. *Note: 1. The PC becomes vulnerable to being hacked if DMZ function starts. Please only use it in need. 2. The PC with DMZ function needs a fixed IP address. 3. DMZ function can only be used in one PC.
WLBARGMO Manual All routing logs are displayed in the table. Activating this function can detect the device or software of LAN, supporting UPnP. For example: online games supporting UPnP or Windows Messenger (Ver. 4.7 or above), MSN Messenger (Ver. 5.0 or above) and so forth. Set its status usable. The default value is [Enable].
WLBARGMO Manual Admin login name User name for login this management program. Default setting is [root]. Admin login password Default password is empty. Password comfirmation Please retype password. Connection Timeout Enter connection time-out time. Back to default setting Click [Proceed] to restore all default values. Reboot New changes only effect after the system reboots. Save Setting Click [Save] to save your setting values as a file.
WLBARGMO Manual *Firmware update (1) Click [Browse] to open the data folder. Follow the route that the firmware saves to select the file. (2) After selection, click [Firmware update]. (3) When the countdown starts, do not click any button. The update will complete soon afterward. *Note: You may proceed [Check for updates] to look up the latest firmware from corega's web page. *Remote control The setting allows accessing the management program via remote control.
WLBARGMO Manual The activation processes are as follows: (1) Select [Enable]. (2) Indicate 1 ~ 9600 for parameters of port range. e.g. ) 8080 (Recommended keeping default values). (3) Click on [Save] after completing settings. e.g. ) Assume the port value is 8080, enter IP address as the type : [http:// xxx.xxx.xxx.xxx: 8080] to access the management program by remote control. *PING testing Enter the IP address into the [Target IP Address] box, then click on [Ping]. It will display the ping testing result.
WLBARGMO Manual System log is displayed in the table. An E-mail address can be set below. Special incidents will be recorded and sent to the appointed E-mail address. After entering all information, click [Save] to save and complete the setting.
7 FAQ WLBARGMO Manual When the installation fails or the connection doesn’t succeed, it’s recommended to take the following actions. (1) Find your problem in the troubleshooting collection. (2) Search on our official website at http://www.corega-asia.com for the latest information of this product. (3) Go to our official website at http://www.corega-asia.com->click [Support] ->select the [Online Customer Support] item->fill the form page and note following information.
WLBARGMO Manual (8) Has all information provided by your ISP been entered correctly? (9) Are the settings of your web browser correct? Q2. Can not access the management program A: Please confirm the following settings. (1)Is the TCP/IP address correct?(Please refer to 3.1) (2)Is the cardbus successfully installed? (Right click [my computer] select [properties]->click[device manager], if a [x] appears symbol on the network adapter icon, please re-install the product.
WLBARGMO Manual (1) Click [Start] => [Programs] => [Command prompt]. (2) Input [ipconfig] => [Enter]. (3) Confirm IP address (which sould be 192.168.1.x). If the IP is incorrect, please enter 1-byte character as [ipconfig /renew] => Press [Enter]. (1) Click [Start] => Click [Run]. (2) Input [winipcfg] in the column => press [Enter]. (3) Select your network adapter to display IP address. The IP should be 192.168.1. x ,if none, please click [Release] => Click [Renew]. Q8.
8 Specifications WLBARGMO Manual Compliance Standard WLAN:IEEE802.11, IEEE802.11b, IEEE802.11g LAN:IEEE802.3, IEEE802.3u, IEEE802.3x Interface WAN:10/100Mbps x 1 Port (RJ-45, Auto MDI/MDI-X) LAN:10/100Mbps x 4 Ports (RJ-45, Auto MDI/MDI-X) Frequency Band 2.412~2.472 GHz Transmission speed IEEE802.11b: 11/5.5/2/1Mbps IEEE802.
About corega WLBARGMO Manual corega可瑞加科技於1996年成立於日本新橫濱，致力於提供多元化的家用 網路產品：包括乙太網路交換器、無線區域網路系列產品、路由器、藍芽 系列產品、以及與網路相關的產品應用及服務。corega目前已是日本專業 家用網路產品的暢銷品牌，並且於 2002年2月於台北成立可瑞加科技，專 注於台灣市場推廣高品質的日系家用網路設備。corega以使用者的需求導 向為最重要的營運方針，多樣化的產品行銷以及通路服務營造corega為最 親切適用的家庭網路設備第一品牌！ 竭誠感謝您購買corega可瑞加系列產品，期待本產品為您帶來更快速便捷 的連線體驗，更期盼日後您家用網路擴充/升級的機會，corega能繼續陪 伴您！ corega K.K.
Appendix WLBARGMO Manual Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
