LLDP Commands
Page 190
Auto-negotiation
Advertised Capabilities
The speed/duplex/flow-control capabilities of the port that are advertised by the
auto-negotiation.
Operational MAU type Indicates the MAU type of the port.
LLDP MED
Capabilities Defines the sender's LLDP-MED capabilities.
Device type Contains a value that indicates whether the sender is a Network Connectivity
Device or Endpoint Device, and if an Endpoint, the Endpoint Class t which it
belongs.
LLDP MED - Network Policy
Application type Indicates the primary function of the application defined for this network policy.
Flags Unknown policy: Policy is required by the device, but is currently unknown.
Tagged VLAN: whether the specified application type is using a tagged or an
untagged VLAN.
VLAN ID VLAN identifier for the application.
Layer 2 priority Layer 2 priority to be used for the specified application.
DSCP DSCP value to be used for the specified application.
LLDP MED - Power Over Ethernet
Power type Indicates whether the device is a Power Sourcing Entity (PSE) or Power Device
(PD).
Power Source Indicates the power source being utilized by a PSE or PD device. A PSE device
advertises its power capability. Available values are: Primary power source and
Backup power source. A PD device advertises its power source. Available
values are: Primary power, Local power, Primary and Local power.
Power priority Indicates the priority of the PD device. A PSE device advertises the power
priority configured for the port. A PD device advertises the power priority
configured for the device. Available values are: Critical, High and Low.
Power value Indicates the total power, in watts, required by a PD device from a PSE device,
or the total power a PSE device is capable of sourcing over a maximum length
cable based on its current configuration.
LLDP MED - Location
Coordinates, Civic
address, ECS ELIN
Displays the raw data of the location information.
Field Description
