Ethernet Configuration Commands
Page 114
The following table describes the fields shown in the display:
ch7
00
00
ch8
00
00
console#
console#
show interfaces counters ethernet
1/e1
Port InUcastPkts InMcastPkts InBcastPkts InOctets
------ ----------- -------------- ----------- -----------
1/e1 0 0 0 0
Port OutUcastPkts OutMcastPkts OutBcastPkts OutOctets
------ ----------- -------------- ------------ ------------
1/e1 0 0 0 0
FCS Errors: 0
Single Collision Frames: 0
Late Collisions: 0
Oversize Packets: 0
Internal MAC Rx Errors: 0
Received Pause Frames: 0
Transmitted Pause Frames: 0
console#
Field Description
InOctets Counted received octets.
InUcastPkts Counted received Unicast packets.
InMcastPkts Counted received Multicast packets.
InBcastPkts Counted received Broadcast packets.
OutOctets Counted transmitted octets.
OutUcastPkts Counted transmitted Unicast packets.
OutMcastPkts Counted transmitted Multicast packets.
OutBcastPkts Counted transmitted Broadcast packets.
FCS Errors Counted received frames that are an integral number of octets in length but do
not pass the FCS check.
Single Collision Frames Counted frames that are involved in a single collision, and are subsequently
transmitted successfully.
