AT-8800 Series Switch Quick Install Guide AT-8824 AT-8848
AT-8800 Series Quick Install Guide Document Number C613-04043-01 REV C Copyright © 2003-2005 Allied Telesyn International, Corp. 19800 North Creek Parkway, Suite 200, Bothell, WA 98011, USA. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn. Allied Telesyn International, Corp. reserves the right to make changes in specifications and other information contained in this document without prior written notice.
Quick Install Guide 3 Documentation Roadmap AT-8800 Series General Customer Support AT-8800 Series Safety and Statutory Information Booklet Visit www.alliedtelesyn.co.nz for the latest documentation, FAQs, and support information.
AT-9800 Series Switch Selecting a Site The switch can be installed in a standard 19-inch rack or on a level surface such as a desktop or bench. When installing the switch, choose a site that: ■ Allows adequate airflow around the switch and its vents. ■ Is free of dust and moisture. ■ Will maintain an ambient temperature range of 0-50º C (32-122º F) and a humidity range of 5-95% non-condensing. ■ Has a reliable and earthed (grounded) power supply circuit, preferably dedicated and filtered.
Quick Install Guide 5 5. Place the switch in its operating location If installing the switch in a rack: • Remove the rubber feet • Attach the rack-mounting brackets. Use the screws provided with the switch to mount it in a rack. Other screws may damage the switch. • 6. Mount the switch in the rack Apply AC power to the switch Plug the power cord into the AC power connector on the switch’s rear panel, as shown in Figure 1.
AT-9800 Series Switch RX and TX terminal locations on SC fibre GBIC ports are the reverse of RX and TX terminal locations on fixed SC fibre ports. When looking at an SC fibre GBIC from the front, the RX terminal is on the left and the TX terminal is on the right. 11. Connect the data cables Make sure each cable connection is secure. The switch will now perform basic Layer 2 switching functions.
Quick Install Guide 7 Use the following command to change the account password: set password Use the following commands to save the configuration with the newly created password and set the switch to use it on bootup: create config=your-name.cfg set config=your-name.cfg To display a list of help topics, enter: help To display help on a specific topic, enter: help topic Alternatively, type a question mark (?) at the end of a partially completed command to see a list of valid options.
AT-9800 Series Switch 6. Save the configuration and set the switch to use it on bootup create config=your-name.cfg set config=your-name.cfg 7. On the PC’s web browser, bypass the HTTP proxy server, if necessary 8. Point your web browser at vlan1’s IP address 9. At the login prompt, enter the user name and password The default username is manager: User Name: manager Password: friend The System Status page is displayed. Select options from the sidebar menu to configure and manage the switch.
