User's Manual

Chapter 21: Security
276
Dial-in User— Local Authentication
Dial-in User feature provides the local authentication server for port
security when a remote (RADIUS) server is not available. This section
includes the following:
 “Overview” on page 276
 “Dial-in User Configuration” on page 276
Note
To permanently save your new settings or any changes to the
configuration file, select Save Configuration to Flash from the
main menu on the left side of the page.
Overview The Dial-in User (local) authentication method allows you to set up 802.1x
authentication parameters internally in the switch. In this case, the user
name and password combinations are entered with an optional VLAN
when they are defined. Based on these entries, the authentication process
of a supplicant is done locally by the AT-S111 Management software
using a standard EAPOL (EAP over LAN) transaction.
Dial-in User
Configuration
The procedures in this section describe how to create, delete, and modify
dial-in users. See the following procedures:
 “Add a Dial-in User” on page 276
 “Modify a Dial-in User” on page 277
 “Delete a Dial-in User” on page 278
Add a Dial-in User
To set up a user’s dial-in access, do the following:
1. From the main menu on the left side of the page, select the Security
folder.
The Security folder expands.
2. From the Security folder, select Dial-in User.
The Dial-in User page is displayed. See Figure 110 on page 277.
