Dimensions Guide

18.000
17.496
1.620
1.130
19.306
P
DETAIL P
SCALE 2 : 3
2
3
5
1
4
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 HB1T-1 HUB 2
2 PSRD8-12 BASE 2
3 CARD-34 END 2
4 TU34-17.5 TUBE 1
5 CRRD-34 RING 2
18 Inch Refrigerator
Pull
6
54
3
D
THIRD ANGLE PROJECTION
APPROVED
0
QUANTITY
FINISH
MATERIAL:
SCALE
C
A4
SHEET: 01
DRAWING No.
DESCRIPTION:
REV
CHECKED
6
5
A
B
4
1
2
3
A
2
1
D
C
B
R.A
TBD
1:1.25
F-30-RP
TBD
DRAWN
I.M
P.D
COPYRIGHT © Allied Brass 2017
5/24/2017
BRASS
.x
.3mm
.xx
.15mm
.xxx
.008mm
UNLESS OTHERWISE STATED
5/24/2017
5/24/2017
