Table 55: Electrical Characteristics and AC Operating Conditions (Continued)
Notes 1–8 apply to the entire table
Parameter Symbol
DDR3L-800 DDR3L-1066 DDR3L-1333 DDR3L-1600
Unit NotesMin Max Min Max Min Max Min Max
WRITE with auto
precharge command to
power-down entry
BL8 (OTF, MRS)
BC4OTF
t
WRAP-
DEN
MIN = WL + 4 + WR + 1 CK
BC4MRS
t
WRAP-
DEN
MIN = WL + 2 + WR + 1 CK
Power-Down Exit Timing
DLL on, any valid command, or DLL off to
commands not requiring locked DLL
t
XP MIN = greater of 3CK or 7.5ns;
MAX = N/A
MIN = greater of 3CK or 6ns;
MAX = N/A
CK
Precharge power-down with DLL off to
commands requiring a locked DLL
t
XPDLL MIN = greater of 10CK or 24ns; MAX = N/A CK 28
ODT Timing
R
TT
synchronous turn-on delay ODTLon CWL + AL - 2CK CK 38
R
TT
synchronous turn-off delay ODTLoff CWL + AL - 2CK CK 40
R
TT
turn-on from ODTL on reference
t
AON –400 400 –300 300 –250 250 –225 225 ps 23, 38
R
TT
turn-off from ODTL off reference
t
AOF 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 CK 39, 40
Asynchronous R
TT
turn-on delay
(power-down with DLL off)
t
AONPD MIN = 2; MAX = 8.5 ns 38
Asynchronous R
TT
turn-off delay
(power-down with DLL off)
t
AOFPD MIN = 2; MAX = 8.5 ns 40
ODT HIGH time with WRITE command and
BL8
ODTH8 MIN = 6; MAX = N/A CK
ODT HIGH time without WRITE command or
with WRITE command and BC4
ODTH4 MIN = 4; MAX = N/A CK
Dynamic ODT Timing
R
TT,nom
-to-R
TT(WR)
change skew ODTLcnw WL - 2CK CK
R
TT(WR)
-to-R
TT,nom
change skew - BC4 ODTLcwn4 4CK + ODTLoff CK
R
TT(WR)
-to-R
TT,nom
change skew - BL8 ODTLcwn8 6CK + ODTLoff CK
R
TT
dynamic change skew
t
ADC 0.3 0.7 0.3 0.7 0.3 0.7 0.3 0.7 CK 39
Write Leveling Timing
First DQS, DQS# rising edge
t
WLMRD 40 – 40 – 40 – 40 – CK
DQS, DQS# delay
t
WLDQSEN 25 – 25 – 25 – 25 – CK
Write leveling setup from rising CK, CK#
crossing to rising DQS, DQS# crossing
t
WLS 325 – 245 – 195 – 165 – ps
8Gb: x4, x8, x16 DDR3L SDRAM
Electrical Characteristics and AC Operating Conditions
78
Rev 2.0 June 2016
