Datasheet

Table 51: DDR3L-1333 Speed Bins
DDR3L-1333 Speed Bin -15E
1
-15
2
Unit Notes
CL-
t
RCD-
t
RP 9-9-9 10-10-10
Parameter Symbol Min Max Min Max
Internal READ command to first data
t
AA 13.5 – 15 – ns
ACTIVATE to internal READ or WRITE delay
time
t
RCD 13.5 – 15 – ns
PRECHARGE command period
t
RP 13.5 – 15 – ns
ACTIVATE-to-ACTIVATE or REFRESH command
period
t
RC 49.5 – 51 – ns
ACTIVATE-to-PRECHARGE command period
t
RAS 36 9 x
t
REFI 36 9 x
t
REFI ns 3
CL = 5 CWL = 5
t
CK (AVG) 3.0 3.3 3.0 3.3 ns 4
CWL = 6, 7
t
CK (AVG) Reserved Reserved ns 5
CL = 6 CWL = 5
t
CK (AVG) 2.5 3.3 2.5 3.3 ns 4
CWL = 6
t
CK (AVG) Reserved Reserved ns 5
CWL = 7
t
CK (AVG) Reserved Reserved ns 5
CL = 7 CWL = 5
t
CK (AVG) Reserved Reserved ns 5
CWL = 6
t
CK (AVG) 1.875 <2.5 Reserved ns 4, 5
CWL = 7
t
CK (AVG) Reserved Reserved ns 5
CL = 8 CWL = 5
t
CK (AVG) Reserved Reserved ns 5
CWL = 6
t
CK (AVG) 1.875 <2.5 1.875 <2.5 ns 4
CWL = 7
t
CK (AVG) Reserved Reserved ns 5
CL = 9 CWL = 5, 6
t
CK (AVG) Reserved Reserved ns 5
CWL = 7
t
CK (AVG) 1.5 <1.875 Reserved ns 4, 5
CL = 10 CWL = 5, 6
t
CK (AVG) Reserved Reserved ns 5
CWL = 7
t
CK (AVG) 1.5 <1.875 1.5 <1.875 ns 4
Supported CL settings 5, 6, 7, 8, 9, 10 5, 6, 8, 10 CK
Supported CWL settings 5, 6, 7 5, 6, 7 CK
Notes:
1. The -15E speed grade is backward compatible with 1066, CL = 7 (-187E).
2. The -15 speed grade is backward compatible with 1066, CL = 8 (-187).
3.
t
REFI depends on T
OPER
.
4. The CL and CWL settings result in
t
CK requirements. When making a selection of
t
CK,
both CL and CWL requirement settings need to be fulfilled.
5. Reserved settings are not allowed.
8Gb: x4, x8, x16 DDR3L SDRAM
Speed Bin Tables
69
Rev 2.0 June 2016
