Slew Rate Definitions for Differential Output Signals
The differential output driver is summarized in Table 46 (page 63). With the reference
load for timing measurements, the output slew rate for falling and rising edges is de-
fined and measured between V
OL(AC)
and V
OH(AC)
for differential signals.
Table 49: Differential Output Slew Rate Definition
Differential Output Slew
Rates (Linear Signals)
Measured
CalculationOutput Edge From To
DQS, DQS# Rising V
OL,diff(AC)
V
OH,diff(AC)
V
OH,diff(AC)
- V
OL,diff(AC)
ΔTR
diff
Falling V
OH,diff(AC)
V
OL,diff(AC)
V
OH,diff(AC)
- V
OL,diff(AC)
ΔTF
diff
Figure 29: Nominal Differential Output Slew Rate Definition for DQS, DQS#
ΔTR
diff
ΔTF
diff
V
OH,diff(AC)
V
OL,diff(AC)
0
