Figure 28: Nominal Slew Rate Definition for Single-Ended Output Signals
V
OH(AC)
V
OL(AC)
V
TT
ΔTF
se
ΔTR
se
8Gb: x4, x8, x16 DDR3L SDRAM
Output Characteristics and Operating Conditions
