Table 9: I
DD0
Measurement Loop
CK, CK#
CKE
Sub- Loop
Cycle Number
Command
CS#
RAS# CAS#
WE#
ODT
BA[2:0]
A[15:11]
A[10]
A[9:7] A[6:3] A[2:0]
Data
Toggling
Static HIGH
0
0 ACT 00110000000 –
1 D 10000000000 –
2 D 10000000000 –
3 D# 11110000000 –
4 D# 11110000000 –
Repeat cycles 1 through 4 until nRAS - 1; truncate if needed
nRAS PRE 00100000000 –
Repeat cycles 1 through 4 until nRC - 1; truncate if needed
nRC ACT 001100000F0 –
nRC + 1 D 100000000F0 –
nRC + 2 D 100000000F0 –
nRC + 3 D# 111100000F0 –
nRC + 4 D# 111100000F0 –
Repeat cycles nRC + 1 through nRC + 4 until nRC - 1 + nRAS -1; truncate if needed
nRC + nRAS PRE 001000000F0 –
Repeat cycles nRC + 1 through nRC + 4 until 2 × RC - 1; truncate if needed
1 2 × nRC Repeat sub-loop 0, use BA[2:0] = 1
2 4 × nRC Repeat sub-loop 0, use BA[2:0] = 2
3 6 × nRC Repeat sub-loop 0, use BA[2:0] = 3
4 8 × nRC Repeat sub-loop 0, use BA[2:0] = 4
5 10 × nRC Repeat sub-loop 0, use BA[2:0] = 5
6 12 × nRC Repeat sub-loop 0, use BA[2:0] = 6
7 14 × nRC Repeat sub-loop 0, use BA[2:0] = 7
Notes:
1. DQ, DQS, DQS# are midlevel.
2. DM is LOW.
3. Only selected bank (single) active.
