Figure 109: Dynamic ODT: ODT Pin Asserted Together with WRITE Command for 6 Clock Cycles, BL8
T0 T1 T2 T3 T4 T5 T6 T7 T8 T9
ODTLcwn8
ODTLon
ODTLcnw
WL
t
AOF (MAX)
T10 T11
CK
CK#
Address
R
TT
ODT
DQ
DQS, DQS#
DI
b + 3
DI
b + 2
DI
b + 1
DI
b
DI
b + 7
DI
b + 6
DI
b + 5
DI
b + 4
Valid
Don’t CareTransitioning
Command
WRS8NOP NOPNOP NOP NOP NOP NOP NOP NOP NOP NOP
R
TT(WR)
ODTH8 ODTLoff
t
ADC (MAX)
t
AON (MIN)
t
AOF (MIN)
Notes:
1. Via MRS or OTF; AL = 0, CWL = 5. If R
TT,nom
can be either enabled or disabled, ODT can be HIGH. R
TT(WR)
is enabled.
2. In this example, ODTH8 = 6 is satisfied exactly.
8Gb: x4, x8, x16 DDR3L SDRAM
Dynamic ODT
193
Rev.2.0 June 2016
