Figure 89: WRITE (BL8) to PRECHARGE
T0 T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 T11 T12 Ta0 Ta1
DI
n + 3
DI
n + 2
DI
n + 1
DI
n
DI
n + 6
DI
n + 7
DI
n + 5
DI
n + 4
NOPWRITE
Valid
NOP NOP NOP NOP NOP NOP NOP NOP NOP NOP NOP NOP PRE
CK
CK#
Command
DQ BL8
DQS, DQS#
Address
Don’t CareTransitioning Data
Indicates break
in time scale
t
WR
WL = AL + CWL
Valid
Notes:
1. DI n = data-in from column n.
2. Seven subsequent elements of data-in are applied in the programmed order following
DO n.
3. Shown for WL = 7 (AL = 0, CWL = 7).
Figure 90: WRITE (BC4 Mode Register Setting) to PRECHARGE
T0 T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 T11 T12 Ta0 Ta1
DI
n + 3
DI
n + 2
DI
n + 1
DI
n
NOPWRITE
Valid
NOP NOP NOP NOP NOP NOP NOP NOP NOP NOP NOP NOP PRE
CK
CK#
Command
DQ BC4
DQS, DQS#
Address
Don’t CareTransitioning Data
Indicates break
in time scale
t
WR
WL = AL + CWL
Valid
Notes:
1. NOP commands are shown for ease of illustration; other commands may be valid at
these times.
2. The write recovery time (
t
WR) is referenced from the first rising clock edge after the last
write data is shown at T7.
t
WR specifies the last burst WRITE cycle until the PRECHARGE
command can be issued to the same bank.
3. The fixed BC4 setting is activated by MR0[1:0] = 10 during the WRITE command at T0.
4. DI n = data-in for column n.
5. BC4 (fixed), WL = 5, RL = 5.
8Gb: x4, x8, x16 DDR3L SDRAM
WRITE Operation
171
