Figure 88: WRITE (BC4 OTF) to READ (BC4 OTF)
WL = 5 RL = 5
T0 T1 T2 T3 T4 T5 T6 T7 T8 T9
t
WPRE
T10 T11
Don’t CareTransitioning Data
Tn
NOPWRITE READ
ValidValid
NOP NOP NOP NOP NOP NOP NOP NOPNOP
CK
CK#
Command
1
DQ
4
DQS, DQS#
Address
3
t
WPST
t
BL = 4 clocks
NOP
t
WTR
2
Indicates break in time scale
DI
n + 3
DI
n + 2
DI
n + 1
DI
n
Notes:
1. NOP commands are shown for ease of illustration; other commands may be valid at these times. 2.
t
WTR controls the WRITE-to-READ delay to the same device and starts after
t
BL.
3. The BC4 OTF setting is activated by MR0[1:0] = 01 and A12 = 0 during the WRITE command at T0 and the READ
command at Tn.
4. DI n = data-in for column n. 5. BC4, RL = 5 (AL = 0, CL = 5), WL = 5 (AL = 0, CWL = 5).
