Figure 64: Example:
t
FAW
Command
Don’t Care
T1T0 T4 T5 T8 T9 T10 T11
t
RRD
Row Row
Bank a Bank b
Row
Bank c
Row
Bank d Bank y
Row
Bank y
NOPACT NOPACT ACT NOP NOP
t
FAW
BA[2:0]
CK#
Address
CK
T19
T20
NOPACT ACT
Bank e
Indicates break
in time scale
8Gb: x4, x8, x16 DDR3L SDRAM
ACTIVATE Operation
152
Rev 2.0 June 2016
