Datasheet

Figure 60: MPR System Read Calibration with BC4: Lower Nibble, Then Upper Nibble
T0 Ta Tb
CK
CK#
DQ
DQS, DQS#
t
MOD
t
MPRR
Don’t Care
Tc0 Tc1 Tc2 Tc3 Tc4 Tc5 Tc6 Tc7 Tc8 Tc9 Tc10 Td
NOP NOP NOP NOP NOP MRS NOP NOP ValidCommand MRSPREA
READ
1
READ
1
NOP NOP
Indicates break in time scale
Bank address 3 Valid 3Valid
0A[1:0] Valid
0
2
0
2
1A2
1
4
0
3
0
00A[9:3] Valid Valid 00
01A10/AP Valid Valid 0 0A11 Valid Valid 0 0A12/BC#
Valid
1
Valid
1
0
0
A[15:13]
Valid Valid 0
RL
RL
t
RF
t
MOD
t
CCD
Notes:
1. READ with BC4 either by MRS or OTF. 2. Memory controller must drive 0 on A[1:0]. 3. A2 = 0 selects lower 4 nibble bits 0 . . . 3. 4. A2 = 1 selects upper 4 nibble bits 4 . . . 7.
8Gb: x4, x8, x16 DDR3L SDRAM
Mode Register 3 (MR3)
147
