Table 75: MPR Readouts and Burst Order Bit Mapping (Continued)
MR3[2] MR3[1:0] Function
Burst
Length
Read
A[2:0]
Burst Order and Data Pattern
1 11 RFU N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
Note:
1. Burst order bit 0 is assigned to LSB, and burst order bit 7 is assigned to MSB of the selec-
ted MPR agent.
8Gb: x4, x8, x16 DDR3L SDRAM
Mode Register 3 (MR3)
144
Rev 2.0 June 2016
