How to Read Table 4
To determine the correct number required to program
Default Cycle, use the following table. The Default
Value column contains the number required in step 5.
The other columns correspond to individual options.
Each column of options contains a unique combination
of the words “ON” and “OFF” that indicates if that
column’s option is turned on or off when the Default
Value is entered. Select the desired combination of options
and enter the number found in the Default Value column.
“+030”
Default Value HIGH TEMP MED TEMP LOW TEMP NO HEAT
1OFFOFFOFF ON
2OFFOFFON OFF
4OFFON OFF OFF
8 ON OFF OFF OFF
Tab le 4
