Instruction manual

Programming NetMaster
511210
98
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
61. Lucky Option “+061”
This option allows the owner to program the machine
to provide a free vend cycle to customers after a
certain number of machine cycles have occurred.
For coin models, “FrEE” will be displayed five
minutes after the completion of the programmed
number of cycles has occurred. The cycle can then be
started by pressing the START (enter) pad.
For card models, when a card is inserted, the VFD will
display “bAL” followed by the card balance. When the
user presses the START pad, a zero vend will be deducted
from the card. The VFD will display “WAIT”. The
VFD will then display “FrEE” for five seconds and
then the cycle time will be displayed. When the card is
removed, the VFD will flash the remaining balance for
three seconds and will then revert back to the cycle time.
How to Program Lucky Option
1. Control must be in Manual Mode. Refer to
Entering the Manual Mode.
2. Press the LOW TEMP (+) or the NO HEAT (-)
keypad until “PrOg” appears in the VFD. Press
the START (enter) keypad and “+001” will
appear in the VFD.
Figure 210
3. Press the LOW TEMP (+) or the NO HEAT (-)
keypad to scroll through the programmable
options until “+061” appears in the VFD. Refer
to Figure 211.
Figure 211
4. When “+061” appears in the VFD, press the
START (enter) keypad. A number will appear in
the VFD. This number corresponds to the current
Lucky Option Programming Value.
5. Locate the desired number in the first column of
Table 8 below.
6. Press the LOW TEMP (+) or the NO HEAT (-)
keypad to increase or decrease the current
number until correct. Refer to Figure 212.
Figure 212
7. Press the START (enter) keypad when the correct
number appears in the VFD. The next option,
“+062”, will appear in the VFD.
NOTE: To program “+062” (Smart Card
Maximum Value), refer to option 62. To program
other options, refer to the appropriate section.
How to Exit Programming Feature
1. Be sure the control shows a programmable option,
not a value.
2. While pressing and holding the MED TEMP
keypad with one hand, press the LOW TEMP
keypad with the other hand. The control will
revert back to the Ready Mode. Refer to Figure 2.
C762I
C861I
“+061”
Lucky Option
Value
Lucky Cycle
ON/OFF
Number of
Cycles
1 – 127 OFF 1 – 127
128 ON 0
129 ON 1
130 ON 2
131 – 255 ON 3 – 127
Tab le 8
C848I
1 Press this pad (+) to scroll forward or increase a value
2 Press this pad (enter) to choose a selected value or
option
3 Press this pad (-) to scroll back or decrease a value
C84
8
1
3
2
