Installation Guide

ASSEMBLY INSTRUCTIONS

Thread wires through mounting plate (B) and plastic

washer (E). Prepare wires by stripping 3/4 in. of

insulation from wire ends using wire strippers (not

included). Connect WHITE wire from fixture (A) to

WHITE wire from outlet box using existing wire

connector or wire connector (AA). Connect BLACK

wire from fixture (A) to BLACK wire from outlet box

using existing wire connector or wire connector (AA).

Connect BARE/GREEN ground wire from outlet box

to BARE ground wire from fixture (A) with wire

connector (AA).

NOTE: Screw wire connectors (AA) on in a

clockwise direction.

WARNING: Never connect ground wire to

WHITE or BLACK power supply wires.

WARNING: To reduce the risk of fire, electrical

shock or personal injury, wire connectors (AA) are

designed to accept only one 12-gauge house wire

and two lead wires from the light fixture. If your house

wire is larger than 12-gauge or there is more than one

house wire to connect to the corresponding fixture

lead wires, consult an electrician for the proper size

wire connectors to use.

Hardware Used

Wire Connector

x 3

Wrap electrical tape (not included) around

each individual wire connector (AA) down

to the wire. Push wire connectors (AA)

gently back into outlet box. Carefully push

excess wiring into outlet box.

WARNING: Make sure no bare wire or

wire strands are visible after making

connections.

Outlet Box
