RPS10 RACK MOUNT POWER SUPPLY USER GUIDE PUBLICATION AP2142
Warranty LIMITED ONE YEAR WARRANTY This product has been manufactured in the UK by ALLEN & HEATH LTD and is warranted to be free from defects in materials or workmanship for a period of one year from the date of purchase by the original owner. To ensure the high level of performance and reliability for which this equipment has been designed and manufactured please read the User Guide before use. In the event of a failure notify and return the defective unit to ALLEN & HEATH Ltd.
RPS10 Power Supply INTRODUCING THE RPS10 The RPS10 is a linear power supply which, like other linear supplies, produces DC voltages by rectifying, smoothing and regulating AC voltages from the secondary windings of a mains transformer. Allen & Heath mixing consoles employ a number of DC voltage supply levels in their operation and these are provided at the output of each unit. IMPORTANT: Please read this manual carefully before connecting your RPS10 power supply to the mains.
Using the RPS10 ALWAYS MAKE SURE THAT THE POWER SUPPLY HAS BEEN SET TO THE SAME AC SOURCE VOLTAGE AS DERIVED VIA THE MAINS SOCKET Always switch the power supply off before connecting or disconnecting the console power cable, removing or installing modules and servicing. In the event of an electrical storm, or large mains voltage fluctuations, immediately switch off the power supply and disconnect from the mains supply.
Installation of the RPS10 Free Standing The RPS10 can be operated as a free standing unit without requiring any special cooling arrangement, but should not be accidentally or deliberately covered in any way. Always stand the unit on a firm flat surface well away from any soft furnishings. Rack Mounting The RPS10 is designed as a 19 inch rack mount unit and will occupy 3U (5.25 inches) of rack space.
Technical Specification Mains Input Voltage Settings 240/220/120/110/100 VAC @ 50/60 Hz Power consumption (max.) 250W Mains Fuse Rating 100-120 VAC 220-240 VAC Use T3.15A/250V Use T1.6A/250V Outputs DC Voltage Rail +16 VOLTS -16 VOLTS +48 VOLTS Output Current 4A Max. 4A Max. 200mA Max.
Servicing THIS UNIT CONTAINS NO USER SERVICEABLE PARTS. REFER ALL SERVICING TO A QUALIFIED SERVICE ENGINEER, THROUGH THE APPROPRIATE ALLEN & HEATH DEALER Initial operational tests on the power supply can be carried out by switching the unit ON and checking the front panel neon indicator is illuminated. If the neon indicator is not illuminated, check the fuses are intact in the mains plug (where fitted) and the front panel fuseholder.
