Instruction Manual

Qu-Pac Getting Started Guide 5 AP9815 iss1
2. Contents
1. Packed contents ................................................................................................................................. 4
2. Contents .............................................................................................................................................. 5
3. Introduction ......................................................................................................................................... 6
4. Installing Qu-Pac ................................................................................................................................. 7
5. Rear Panel ........................................................................................................................................... 8
6. Front Panel ........................................................................................................................................ 10
7. Audio Signal Processing .................................................................................................................. 12
8. Operating Qu-Pac ............................................................................................................................. 13
8.1 Mixing using the Front Panel Controls .................................................................................... 13
8.2 Mixing using Wireless Control ................................................................................................. 15
8.3 Qu-Control................................................................................................................................ 17
9. Resetting the Mixer ........................................................................................................................... 18
9.1 Reset Mix Settings – A starting point for mixing ...................................................................... 18
9.2 System Hard Reset .................................................................................................................. 19
About this guide
This is the Getting Started Guide for the Allen & Heath Qu-Pac rack
mount digital mixer.
For more information about Qu-Pac setup and mixing functions please
refer to the Qu Mixer Reference Guide available for download from
the Allen & Heath website:
www.allen-heath.com
Please Note
This guide refers to Qu firmware V1.7. Please refer to the Allen &
Heath website for the latest version of firmware and this guide.
For information on the AR2412, AR84 and AB168 remote AudioRacks
please refer to their user guides.
