Channel Mutes
Pressing any input or output channel MUTE switch
transmits a MIDI Note On message. Similarly,
receiving a MIDI Note On message will turn the
associated channel mute on or off, unless the
channel has been made automation safe.
Console mutes are mapped to MIDI Note numbers
as shown in the table. Running status is supported
on receive and transmit.
Transmit. Pressing a channel MUTE switch
transmits the following Note On messages:
9n cc vv 9n cc 00
Where n = console MIDI channel number
cc = input or output channel number
vv = 3FH for mute off, 7FH for mute on
Receive. The console responds to the following
MIDI Note On message:
9n cc vv (00 is ignored)
Where vv < 40 = mute off,
40 <= vv <= 7F = mute on
Snapshot Memories
Recalling a snapshot will transmit a MIDI Program
Change message. Receiving a Program Change
message will recall a snapshot.
Snapshot numbers 1 to 128 are mapped to MIDI
Program Change numbers 0 to 127. Running
status is supported on receive and transmit.
Transmit and Receive. The message format is:
Cn pp
Where n = console MIDI channel number
pp = console snapshot number 00 to 7F
MIDI AFL Messages
SysEx message strings are transmitted each time
an output channel AFL switch is selected or
released. These are for use with BSS and dbx
speaker management systems to automatically
select the remote control surface associated with
the output being AFL monitored.
BSS Omnidrive
F0 00 20 18 7F 20 cc F7
dbx Drive Rack
F0 00 01 1E 7F 7F 20 cc F7
These messages are subject to further development
and addition. Please check the Allen & Heath Web
site for the latest information.
Standard ''B' versions
HEX (cc) MUTE 32ch 40 & 48ch
00 GRP/AUX 1 GRP/AUX 1 GRP/AUX 1
01 GRP/AUX 2 GRP/AUX 2 GRP/AUX 2
02 GRP/AUX 3 GRP/AUX 3 GRP/AUX 3
03 GRP/AUX 4 GRP/AUX 4 GRP/AUX 4
04 GRP/AUX 5 GRP/AUX 5 GRP/AUX 5
05 GRP/AUX 6 GRP/AUX 6 GRP/AUX 6
06 GRP/AUX 7 GRP/AUX 7 GRP/AUX 7
07 GRP/AUX 8 GRP/AUX 8 GRP/AUX 8
08 AUX 9 AUX 9 AUX 9
09 AUX 10 AUX 10 AUX 10
0A AUX 11 AUX 11 AUX 11
0B AUX 12 AUX 12 AUX 12
0C AUX 13 AUX 13 AUX 13
0D AUX 14 AUX 14 AUX 14
0E AUX 15 AUX 15 AUX 15
0F AUX 16 AUX 16 AUX 16
10 MATRIX 1 MATRIX 1 MATRIX 1
11 MATRIX 2 MATRIX 2 MATRIX 2
12 MATRIX 3 MATRIX 3 MATRIX 3
13 MATRIX 4 MATRIX 4 MATRIX 4
14 MATRIX 5 MATRIX 5 MATRIX 5
15 MATRIX 6 MATRIX 6 MATRIX 6
16 MATRIX 7 MATRIX 7 MATRIX 7
17 MATRIX 8 MATRIX 8 MATRIX 8
20 CH 1 CH 1 CH 1
21 CH 2 CH 2 CH 2
22 CH 3 CH 3 CH 3
23 CH 4 CH 4 CH 4
24 CH 5 CH 5 CH 5
25 CH 6 CH 6 CH 6
26 CH 7 CH 7 CH 7
27 CH 8 CH 8 CH 8
28 CH 9 CH 9 CH 9
29 CH 10 CH 10 CH 10
2A CH 11 CH 11 CH 11
2B CH 12 CH 12 CH 12
2C CH 13 CH 13 CH 13
2D CH 14 CH 14 CH 14
2E CH 15 CH 15 CH 15
2F CH 16 CH 16 CH 16
30 CH 17 STEREO 5 CH 17
31 CH 18 STEREO 6 CH 18
32 CH 19 STEREO 7 CH 19
33 CH 20 STEREO 8 CH 20
34 CH 21 CH 17 CH 21
35 CH 22 CH 18 CH 22
36 CH 23 CH 19 CH 23
37 CH 24 CH 20 CH 24
38 CH 25 CH 21 STEREO 5
39 CH 26 CH 22 STEREO 6
3A CH 27 CH 23 STEREO 7
3B CH 28 CH 24 STEREO 8
3C CH 29 CH 25 CH 25
3D CH 30 CH 26 CH 26
3E CH 31 CH 27 CH 27
3F CH 32 CH 28 CH 28
40 CH 33 CH 29 CH 29
41 CH 34 CH 30 CH 30
42 CH 35 CH 31 CH 31
43 CH 36 CH 32 CH 32
44 CH 37 CH 33 CH 33
45 CH 38 CH 34 CH 34
46 CH 39 CH 35 CH 35
47 CH 40 CH 36 CH 36
48 CH 41 CH 37 CH 37
49 CH 42 CH 38 CH 38
4A CH 43 CH 39 CH 39
4B CH 44 CH 40 CH 40
4C CH 45 CH 41 CH 41
4D CH 46 CH 42 CH 42
4E CH 47 CH 43 CH 43
4F CH 48 CH 44 CH 44
50 STEREO 1 STEREO 1 STEREO 1
51 STEREO 2 STEREO 2 STEREO 2
52 STEREO 3 STEREO 3 STEREO 3
53 STEREO 4 STEREO 4 STEREO 4
54 MAIN L MAIN L MAIN L
55 MAIN R MAIN R MAIN R
56 MAIN C MAIN C MAIN C
