User's Manual Part 1

8065751025 1.5
Constellation
®
Vision System
Figure 1-2 ICONS USED WITH THE Constellation
®
Vision System - Icons identifying modes, functions, etc., that
are used with the Constellation
®
Vision System are identified in this chart.
Extrusion
Forceps
Fragmentation
Irrigation/
Aspiration
Laser
Phaco
Scissors
Viscous
Fluid
Control
(VFC)
Vitrectomy
Expand
Window
Help Video
Modify
Power
Save
Air Pressure
Input
Auto Gas Filling
(AGF)
Alternating
Current
Coagulation
Connector
Connection
Indicator
Dangerous
Voltage
Eject
Equipotentiality
Footswitch
Forceps
Fuse
Hot
1
Illuminator
Laser
Connection
Laser
Emergency Stop
Switch
1
Laser Port 1
Tethered Laser
Network
Connection
Off
On
!
Consult
Operator's
Manual, or
System Error or
Advisory
Opens
Operator's
Manual
Video Recorder
Scissors
Connector
Serial In/Out
Standby State
SYSTEM
FAULT
System Fault
System
Information
Type BF
Equipment
Type B
Equipment
U/S Handpiece
Connector
USB Connector
Use appropriate
take-back
system (see
Environmental
Considerations in
this manual).
Viscous
Fluid Control
Connector
VGA Out
Video In/Out
Vitreous Cutter
Connection
