Alcatel-Lucent 7450 Ethernet Service Switch | Data Sheet 5
Technical specifications
PER IOM CAPACITY 7450 ESS IOM3-XP 7450 ESS IOM-1
Slot requirements • Single-slot module • Single-slot module
MDA/ISA supported per IOM • Two MDAs or ISAs • Two MDAs or ISAs
MDA type supported • MDA and MDA-XP • MDA and MDA-XP
IOM full-slot throughput • 50 Gb/s • 20 Gb/s
MDA per-half-slot throughput • Up to 25 Gb/s per MDA for a total of • Up to 10 Gb/s per MDA for a total of
50 Gb/s per IOM 20 Gb/s per IOM
Indicators • Operational: Solid green; Fault: Amber • Not applicable
Supported chassis • 7450 ESS-12 • 7450 ESS-12
• 7450 ESS-7 • 7450 ESS-7
• 7450 ESS-6 • 7450 ESS-6
Minimum operating system software • SR OS Release 6.1 • SR OS Release 4.0 or higher MDA support varies
by SR OS release
Dimensions and weight • Standard IOM slot form factor • Standard IOM slot form factor
• IOM3-XP weight empty: 4.99 kg (11 lb) • IOM-1 weight empty: 4.08 kg (9 lb)
Environmental specifications • Operating temperature: 0°C to 40°C (32°F to 104°F)
• Relative humidity: 15% to 85% (non-condensing)
• Operating altitude: 3048 m (10,000 ft)
Network/element management • Fully supported by Alcatel-Lucent 5620 • Fully supported by 5620 SAM
Service Aware Manager (SAM) • Command line interface
• Command line interface
Hardware queues • Hierarchical service queues: 64,000 – • Hierarchical service queues: 32,000 – assignable
available to all IOM-attached ports in 16,000 blocks to each MDA
• Shapers: 64,000 (1-per queue) • Shapers: 32,000 (1 per queue)
Hardware policers* • 1 million 2-tier policers • 16,000
MAC address capacity* • Up to 2 million 2-tier MAC FIBs • Up to 128,000 (hardware/software)
Access Control List* • Up to 174,000 entries per IOM • Up to 96,000 entries per IOM
• System scaling up to 1.7 million entries • System scaling up to 96,000 entries
Safety • EN 60950-1
• IEC 60950-1 CB Scheme
• CSA/UL 60950-1 NRTL
• FDA CDRH 21-CFR 1040
• EN 60825-1
• EN 60825-2
• IEC 60825-1
• IEC 60825-2
EMC • ICES-003 Class A
• FCC Part 15 Class A
• EN 300 386
• EN 55022
• EN 55024
• EN 61000-4-2
• EN 61000-4-3
• EN 61000-4-4
• EN 61000-4-5
• EN 61000-4-6
• EN 61000-4-11
• IEC CISPR22
• AS/NZS CISPR 22
Immunity • EN 61000-3-2 Power Line Harmonics
• EN 61000-3-3 Voltage Fluctuations and Flicker
• EN 61000-4-2 ESD
• EN 61000-4-3 Radiated Immunity
• EN 61000-4-4 EFT
• EN 61000-4-5 Surge
• EN 61000-4-6 Low Frequency Common Immunity
• EN 61000-4-11 Voltage Dips and Sags
