dhcp client flush
Flush complete DHCP client configuration and dynamic interfaces.
The flush command does not impact previously saved configurations.
SYNTAX:
dhcp client flush
EXAMPLE:
=>dhcp client iflist
NewMer : [SELECTING]
flags = uc
IP address : 10.0.0.10
HW address : 0:90:d0:01:47:de
DHCP server : 255.255.255.255
hostname : NewLease
req.leasetime= 10800 s
trying to get a lease for 8 min, 32 sec
transmission of DISCOVER in 57 sec
retransmission timeout: 64
nbr of retransmissions: 14
Number of leases: 1
Total size of table: 19, in use: 1, free: 94 %
=>dhcp client flush
=>dhcp client iflist
No dynamic interfaces defined.
=>
RELATED COMMANDS:
dhcp client load Load saved or default DHCP client configuration and dynamic
interfaces.
dhcp client save Save current DHCP client configuration and dynamic interfaces.
