User Guide

5 Config Commands
60 / 260
3EC 16982 AFAA TCZZA Ed. 01
config load
Load complete saved or default configuration. Execute config flush prior to config load.
In case the saved configuration is loaded (defaults=no) this combines all load commands: atmf
load, bridge load, cip load, dhcp client load, dhcp server load, dns load, firewall load,
firewall rule load, mer load, nat load, phonebook load, ppp load, pptp load, qosbook
load, system load and optionally ip load.
SYNTAX:
config load [load_ip = <{no|yes}>]
[defaults = {yes|no}]
[load_ip] Load IP settings (yes) or not (no).
Not keeping the IP settings could cause lost IP connectivity in the
LAN.
OPTIONAL
[defaults] Load default configuration (yes) or saved configuration (no).
Not specifying this parameter loads the saved configuration
OPTIONAL
EXAMPLE:
=>ip rtlist
Destination Source Gateway Intf Mtrc
10.0.0.0/24 10.0.0.0/24 10.0.0.140 eth0 0
172.16.0.5/32 0.0.0.0/0 172.16.0.5 cip1 0
0.0.0.140/32 0.0.0.0/0 10.0.0.140 eth0 0
127.0.0.1/32 0.0.0.0/0 127.0.0.1 loop 0
10.0.0.0/24 0.0.0.0/0 10.0.0.140 eth0 0
172.16.0.0/24 0.0.0.0/0 172.16.0.5 cip1 1
=>config flush flush_ip=no
=>ip rtlist
Destination Source Gateway Intf Mtrc
10.0.0.0/24 10.0.0.0/24 10.0.0.140 eth0 0
10.0.0.140/32 0.0.0.0/0 10.0.0.140 eth0 0
127.0.0.1/32 0.0.0.0/0 127.0.0.1 loop 0
10.0.0.0/24 0.0.0.0/0 10.0.0.140 eth0 0
=>config load load_ip=yes
=>ip rtlist
Destination Source Gateway Intf Mtrc
10.0.0.0/24 10.0.0.0/24 10.0.0.140 eth0 0
10.0.0.140/32 0.0.0.0/0 10.0.0.140 eth0 0
172.16.0.5/32 0.0.0.0/0 172.16.0.5 cip1 0
127.0.0.1/32 0.0.0.0/0 127.0.0.1 loop 0
10.0.0.0/24 0.0.0.0/0 10.0.0.140 eth0 0
172.16.0.0/24 0.0.0.0/0 172.16.0.5 cip1 1
=>
RELATED COMMANDS:
config erase Physically remove all saved configurations.
config flush Flush complete runtime configuration.
config reset Flush current and optionally restore default configuration.
config save Save current runtime configuration.
