cip iflist
Show current CIP configuration.
SYNTAX:
cip iflist
EXAMPLE OUTPUT:
=>cip iflist
cip0 addr = 172.16.1.1 mask = 255.255.255.0
UNI address = A0:*.03
inarp_reqs_in = 0 inarp_repl_in = 0 inarp_inv_in = 0
inarp_reqs_out = 0 inarp_repl_out = 0 inarp_inv_out= 0
cip1 addr = 172.16.0.5 mask = 255.255.255.0
UNI address = A0:*.04
inarp_reqs_in = 0 inarp_repl_in = 0 inarp_inv_in = 0
inarp_reqs_out = 0 inarp_repl_out = 0 inarp_inv_out= 0
=>
DESCRIPTION:
inarp_reqs_in/inarp_reqs_out : Incoming/outgoing inverse ARP requests
inarp_repl_in/inarp_repl_out : Incoming/outgoing inverse ARP replies
inarp_inv_in/inarp_inv_out : Incoming/outgoing invalid inverse ARP messages
EXAMPLE INPUT/OUTPUT: EVOLUTION OF ARP REQUESTS IN A NETWORKED ENVIRONMENT:
=>cip iflist
cip0 addr = 200.200.200.138 mask = 255.255.255.0
UNI address = A0:*.03
inarp_reqs_in = 18 inarp_repl_in = 75 inarp_inv_in = 0
inarp_reqs_out = 18 inarp_repl_out = 75 inarp_inv_out= 0
=>cip iflist
cip0 addr = 200.200.200.138 mask = 255.255.255.0
UNI address = A0:*.03
inarp_reqs_in = 22 inarp_repl_in = 75 inarp_inv_in = 0
inarp_reqs_out = 22 inarp_repl_out = 75 inarp_inv_out= 0
=>cip iflist
cip0 addr = 200.200.200.138 mask = 255.255.255.0
UNI address = A0:*.03
inarp_reqs_in = 22 inarp_repl_in = 76 inarp_inv_in = 0
inarp_reqs_out = 22 inarp_repl_out = 76 inarp_inv_out= 0
=>
RELATED COMMANDS:
cip ifadd Create a CIP interface.
cip ifdelete Delete a CIP interface.
