shdsl psd
Configure the PSD mask to be used, then restart the SHDSL line.
SYNTAX:
shdsl psd mask = <{sym_NA|sym_EU|asym_NA_768|asym_NA_1536|
asym_EU_2048| asym_EU_2304}>
mask The selected PSD mask must comply to the regional demands and to
the required payload rate.
Choose between:
 sym_NA
Symmetric PSD mask for North America
 sym_EU
Symmetric PSD mask for Europe
 asym_NA_768
Asymmetric PSD mask for 768kbps (North American)
 asym_NA_1536
Asymmetric PSD mask for 1536bps (North American)
 asym_EU_2048
Asymmetric PSD mask for 2048bps (European)
 asym_EU_2304
Asymmetric PSD mask for 2304bps (European)
REQUIRED
EXAMPLE:
=>shdsl info
WAN interface : SHDSL
Line Status : UP at 2304 kbit/s
Total bytes since power on:
Downstream : 9932253 Upstream : 244701
PSD mask : Symmetric PSD mask for Europe
Shdsl uptime : 0:0:21
SNR margin : 7 dB
Attenuation : 24 dB
Transmit Power : 15 dBm
=>shdsl psd mask=asym_EU_2304
=>shdsl info
WAN interface : SHDSL
Line Status : DATA MODE
Total bytes since power on:
Downstream : 0 Upstream : 0
PSD mask : Asymmetric PSD mask for 2304kbps (European)
Shdsl uptime : 0:00:00
=>
