nat delete
Delete a static NAPT entry.
SYNTAX:
nat delete protocol = <IP protocol name or number>
inside_addr = <ip-address>
[inside_port = <TCP/UDP service name or port number>]
outside_addr = <ip-address>
[outside_por =t <TCP/UDP service name or port number>]
protocol The IP protocol name (or number) of the NAT entry. REQUIRED
inside_addr The IP address of the NAT entry. REQUIRED
[inside_port] The port number of the NAT entry. OPTIONAL
outside_addr The apparent host IP address of the NAT entry. REQUIRED
[outside_port] The apparent port number of the NAT entry. OPTIONAL
EXAMPLE:
=>nat list
Indx Prot Inside–addr:PortOutside–addr:Port Foreign–addr:Port Flgs Expir State Control
1 6 10.0.0.138:80 172.16.0.5:1080 0.0.0.0:0 19 8 9
2 17 10.0.0.138:138 10.0.0.140:138 10.0.0.20:138 11 20 10
3 17 10.0.0.138:137 10.0.0.140:137 10.0.0.254:137 11 20 10
4 17 10.0.0.138:7938 10.0.0.140:7938 10.0.0.96:4756 11 20 10
5 17 10.0.0.138:513 10.0.0.140:513 10.0.0.109:513 11 20 10
6 17 10.0.0.138:111 10.0.0.140:111 10.0.0.96:4756 11 20 10
=>nat delete protocol=tcp inside_addr=10.0.0.138 inside_port=80 outside_addr=172.16.0.5
outside_port 1080
=>nat list
Indx Prot Inside–addr:PortOutside–addr:Port Foreign–addr:Port Flgs Expir State Control
1 17 10.0.0.138:138 10.0.0.140:138 10.0.0.20:138 11 20 10
2 17 10.0.0.138:137 10.0.0.140:137 10.0.0.254:137 11 20 10
3 17 10.0.0.138:7938 10.0.0.140:7938 10.0.0.96:4756 11 20 10
4 17 10.0.0.138:513 10.0.0.140:513 10.0.0.109:513 11 20 10
5 17 10.0.0.138:111 10.0.0.140:111 10.0.0.96:4756 11 20 10
=>
RELATED COMMANDS:
nat create Create a static NAPT entry.
nat disable Disable NAPT on one of the SpeedTouchPro with Firewall IP
addresses.
nat enable Enable NAPT on one of the SpeedTouchPro with Firewall IP
addresses.
nat list List NAPT connection database.
