User Guide

17 / 260
3EC 16982 AFAA TCZZA Ed. 01
Command Line Interface Commands
All CLI commands are commands that operate on, or configure, the SpeedTouchPro with
Firewall.
You can execute these commands from top level, preceded by the name of the command group
from which the command should be executed (e. g. firewall list).
You can also execute the commands from the command group itself, using the reduced form of the
command (e.g. list at the firewall command group selection).
`!` in a command means `NOT`, e.g. the `[!]syn` parameter in the firewall rule create command.
EXAMPLE:
=>firewall list
assign hook=input chain=input
assign hook=sink chain=sink
assign hook=forward chain=forward
assign hook=source chain=source
=>firewall
[firewall]=>list
assign hook=input chain=input
assign hook=sink chain=sink
assign hook=forward chain=forward
assign hook=source chain=source
[firewall]=>
Instead of entering a completely builtup command with all its parameters, you can also enter just
the command itself, without its parameters. After this you are prompted to complete the command
with the required and the optional parameters. For the optional parameters you can simply press
enter without giving a value.
The example below is the equivalent of `firewall assign hook=input chain=input`. To break of
such incomplete command press Ctrl+G".
EXAMPLE:
=>firewall assign
hook = input
chain = input
=>
