[defragmode] Define which packets are reassembled under which circumstances.
Choose between:
normal
Packets to be forwarded will not be reassembled.
Packets with local destination, i.e. destined for the
SpeedTouchPro with Firewall, are reassembled.
always
Packets are always reassembled.
nat
Same behaviour as normal except for packets to be forwarded
through the NAT engine.
Packets on which address translation is performed are
reassembled as the NAT engine requires the entire packet.
OPTIONAL
[addrcheck] Set the level of IP address checks.
Choose between:
off
No address checking is performed.
For advanced users only; in normal circumstances there should
always be some kind of address checking.
own
Minimum level of checking.
Only the address configuration on the SpeedTouchPro with
Firewall is checked.
static
Checking of the address configuration of the SpeedTouchPro
with Firewall and also of traffic: addresses of incoming
packets; this checking is related to constants (e. g. an address
may not be entirely composed of one`s or zero`s).
dynamic
Besides the address configuration of the SpeedTouchPro
with Firewall itself, and besides the checking of traffic on a
constants level, additional checking is performed on the IP
addresses that are determined by the configuration, more
specifically by the network.
OPTIONAL
[mssclamping] Disable (off) or enable (on) mss clamping for low mtu interfaces.
Mss clamping assures that the size of a TCP packet never exceeds the
available mtu of the outgoing interface.
It is recommended not to disable this parameter.
OPTIONAL
