OmniAccess 4308: Installation Guide
26 Part 031638-00 May 2005
To connect the required RS-232 serial cable to a terminal with a DB-9 male
port, use the included adapter. Pin-outs are shown in Figure B-5 :
FIGURE B-5 Serial Port Adapter
Communications Settings
TABLE B-8 Console Terminal Settings
Baud Rate Data Bits Parity Stop Bits Flow Control
9600 8 None 1 None
3
4
5
2
5
63
RJ-45 DB-9
Internal
Connections
TxD
GND
RxD
1
2
3
4
5
6
7
8
TxD
TGND
RGND
RxD
RJ-45 Female
Pin-Out
Direction
Input
Output
DB-9 Female
Pin-Out
TxD
RxD
Ground
5
4
3
2
1
9
8
7
6
Direction
Input
Output
