User Guide

System Overview 3

Chapter 1

System Indicator LEDs

Eight FE ports

These network ports are used for connecting wireless APs, such as the

Alcatel Wireless Access Point, as well as wired LAN segments. The ports

provide 10/100 Mbps Fast Ethernet connectivity, and in some cases, power

and serial connectivity as well. See “FE Network Ports” on page 18 for port,

LED, and cable specifications.

GE uplink port

This uplink port is used for high-speed connection to the wired LAN. The port

provides 10/100/1000 Mbps Gigabit Ethernet connection. Depending on the

option selected at time of purchase, one of the following interfaces is

available:

z 1000BASE-T copper connector (standard model OAW-4308T)

z 1000BASE-SX fiber-optic connector (optional model OAW-4308SX)

See “GE Uplink Port” on page 22 for port, LED, and cable specifications.

OTE—The Gigabit interface is not user-replaceable. Do not remove the port

cover plate.

TABLE 1-1 System LEDs

LED State Description

Power

Green Switch is receiving proper power.

Off Switch is powered off.

Status

Green Switch has booted and is functioning

properly.

Off Switch is booting, loading software, or

has failed.

CAUTION—This model uses a laser transceiver on the fiber-optic

uplink port. Use of controls or adjustments of performance or

procedures other than those specified herein may result in

hazardous radiation exposure.
