Alcatel-Lucent 7750 Service Router | Data Sheet 3
Technical specifications
Physical dimensions
• Height:13mm(0.5in)
• Width:171mm(6.7in)
• Depth:178mm(7.0in)
• Weight:0.45kg(1.0lb)
Environmental specifications
• Operatingtemperature:0°Cto
40°C(32°Fto104°F)
• Relativehumidity:15%to85%
(non-condensing)
• Operatingaltitude:3048m(10,000ft)
Network/element management
• FullysupportedbyAlcatel-Lucent
5620 Service Aware Manager (SAM)
• Commandlineinterface(CLI)
Indicators
• Operational:Solidgreen
• Fault:Amber
Minimum operating
system (OS) software
• 7750SROS,Release6.1
Optical Digital Diagnostic
Monitoring (DDM)
architecture compliance
• SFF-8472
Safety
• EN60950-1
• IEC60950-1CBScheme
• CSA/UL60950-1NRTL
• FDACDRH21-CFR1040
• EN60825-1
• EN60825-2
• IEC60825-1
• IEC60825-2
Electromagnetic
compatibility (EMC)
• ICES-003ClassA
• FCCPart15ClassA
• EN300386
• EN55022
• EN55024
• EN61000-4-2
• EN61000-4-3
• EN61000-4-4
• EN61000-4-5
• EN61000-4-6
• EN61000-4-11
• IECCISPR22
• AS/NZSCISPR22
Immunity
• EN61000-3-2PowerLineHarmonics
• EN61000-3-3VoltageFluctuations
and Flicker
• EN61000-4-2ESD
• EN61000-4-3RadiatedImmunity
• EN61000-4-4EFT
• EN61000-4-5Surge
• EN61000-4-6LowFrequency
Common Immunity
• EN61000-4-11VoltageDips
and Sags
Telecom
• TelcordiaGR-253-COREIssue3
• IEEE802.3(GigE,Ethernet)
• ANSIT1.105
• ANSIT1.105.03
• ANSIT1.105.06
• ANSIT1.105.09
• ANSIT1.403(DS1)
• ANSIT1.404(DS3)
• ITU-TG.957
• ITU-TG.825
• ITU-TG.824
• ITU-TG.823
• ITU-TG.813
• ITU-TG.707
• ITU-TG.703
Environmental
• ETS300019-1-1,StorageTests,
Class 1.2
• ETS300019-1-2,Transportation
Tests, Class 2.3
• ETS300019-1-3,OperationalTests,
Class 3.2
• ETS300019-2-4,prA1Seismic
Electronic equipment directives
•WEEE
• RoHS
• R&TTE
•China-CRoHS
Certifications
• NEBSLevel3:
¬TelcordiaGR-1089CORE,Issue4,
June 2006
¬TelcordiaGR-63CORE,Issue3,
March 2006
¬ ATT-TP-76200
• CE
Ordering information
• Partnumber:3HE03073AA
• Description:7750SR10xGigE
HS-MDA
• Interfacetype:PluggableSFP-LC
