- Alcatel Owner's Manual Mobile Telephone One Touch 531
Table Of Contents
- English
- One TouchTM 531
- Introduction
- Using this guide
- Getting Started
- Network services
- Phone Book
- Messages
- Calls & Times
- Settings
- Key
- Action
- Feature
- Default setting
- Divert options
- Action
- Option
- Description
- Select
- Meaning
- Pass word
- Length
- Number of al lowed trials
- If blocked or forgot ten
- Phone lock code
- 4 digits
- Unlimited
- Return phone to manufac turer
- PIN
- 4-8 digits
- 3
- Un blocked by use of PUK code
- PIN2
- 4-8 digits
- 3
- Un blocked by use of PUK2
- PUK
- 8 digits
- 10
- Contact your service provider
- PUK2
- 8 digits
- 10
- Contact your service provider
- Call bar ring pass word
- 4 digits
- Defined by service provider
- Contact your service provider
- Office Tools
- Connectivity
- Games
- WAP™
- To enter and store the profile details via the Assistant
- To enter and store the profile details in standard mode
- 1.All the requested parameters are obtainable from your network operator and/or services provider.
- 2. The phone number or access point name, the login and the password are automatically stored in the Con nection Manager (see Connection manager, page 51).
- 3. A profile name cannot be stored twice. If an error message is displayed please also check the profile names in the Connection profiles (see Connection manager, page 51).
- 4. Access to the connection settings may depend on the pre-programmation of the settings. The connection settings menu may not be available in some cases. These settings may be 'Locked' and not be user pro grammable.
- 5. You can request the activation of the security fea ture from the profiles list (Settings / Activate security).
- 6. Your service provider may require to have the secu rity context reset. Select Yes.
- Getting to the Options menu while online.
- Ending the online connection
- Creating bookmarks
- Using bookmarks
- Other site
- Receiving push messages
- Melodies download
- Customising your mobile
- Wallpaper
- Logo
- Appendix
- 1. use not conforming with the instruc tions for use or installation,
- 2. non observation of the technical and safety standards applicable in the country where the equipment is used,
- 3. improper maintenance of batteries and other sources of energy, and of the overall electric installation,
- 4. accidents or the consequences of theft, (of the vehicle), acts of vandal ism, lightning, fire, humidity, infiltra tion of liquids, atmospheric influences,
- 5. combination or integration of the equipment in hardware not supplied or not recommended by Alcatel, without express written consent for such,
- 6. modifications, alterations, or repairs carried out by parties not authorised by Alcatel, the dealer or the approved maintenance centre,
- 7. use of the equipment for a purpose other than that for which it was de signed,
- 8. normal wear,
- 9. deterioration caused by external caus es (RF interference produced by other equipment, fluctuations in mains volt age and/or voltages on telephone lines, etc),
- 10. modifications made to the equipment even if they are unavoidable due to changes in regulations and/or modifi cation of network parameters,
- 11. connection faults resulting from unsat isfactory radio transmission or caused by the absence of radio relay coverage.
- A
- B
- C
- D
- E
- F
- G
- I
- K
- L
- M
- N
- O
- P
- R
- S
- T
- V
- W
65
Trouble shooting
Problem
Possible cause and solu-
tion
Phone does
not switch on
Check that the battery is
fully charged and correctly
connected to the phone.
No flashing
battery icon
while charg-
ing
There may be no mains
supply. Try a different elec-
trical socket.
The AC/DC charger may be
faulty. Return to your deal-
er and try substitution
with another Alcatel adap-
tor. If faulty contact your
dealer.
Short stand
by and talk
times
Cell broadcast is perma-
nently on, using more bat-
tery power.
Phone is in a poor signal
area and therefore always
on full power.
Incorrect charging and dis-
charging. Always charge
and discharge your battery
fully.
The battery is wearing out.
Replace the battery.
Impossible to
dial numbers
Keypad lock is on ( ap-
pears). Press Unlock
and to turn the keypad
lock off.
Impossible to
make or re-
ceive a call
Check at least one signal
strength bar ( ) is dis-
played. Try a stronger sig-
nal strength area.
If no network name is dis-
played, check registration
and area coverage with
your service/network pro-
vider and check the SIM is
correctly inserted.
Call barring option is on.
Deactivate it (see page 39).
Call cost limit is reached
(see page 29).
Problem
Possible cause and so-
lution
Stored tele-
phone num-
bers cannot
be recalled
Fixed Dialled Number or
Call Barring features are
activated. Deactivate fea-
ture. (see pages 39).
The mobile is
on but noth-
ing is dis-
played.
Display contrast is down
too low. Reset contrast
(see page 34).
Battery icon
not flash-
ing 1-2-3-4-5
during charg-
ing
May indicate a charge or
battery problem. Discon-
nect the charger. Recon-
nect and try again.
May also indicate the bat-
tery is full and does not
need more charging.
Flashing
There is not enough mem-
ory to store another SMS
message. You must delete
one or more of the exist-
ing stored messages (see
page 20).
(......)
softkey
Function no longer availa-
ble in the SIM or was sub-
scription dependent.
Reprogram the softkey
(see page 12).
