- Alcatel Owner's Manual Mobile Telephone One Touch 531
Table Of Contents
- English
- One TouchTM 531
- Introduction
- Using this guide
- Getting Started
- Network services
- Phone Book
- Messages
- Calls & Times
- Settings
- Key
- Action
- Feature
- Default setting
- Divert options
- Action
- Option
- Description
- Select
- Meaning
- Pass word
- Length
- Number of al lowed trials
- If blocked or forgot ten
- Phone lock code
- 4 digits
- Unlimited
- Return phone to manufac turer
- PIN
- 4-8 digits
- 3
- Un blocked by use of PUK code
- PIN2
- 4-8 digits
- 3
- Un blocked by use of PUK2
- PUK
- 8 digits
- 10
- Contact your service provider
- PUK2
- 8 digits
- 10
- Contact your service provider
- Call bar ring pass word
- 4 digits
- Defined by service provider
- Contact your service provider
- Office Tools
- Connectivity
- Games
- WAP™
- To enter and store the profile details via the Assistant
- To enter and store the profile details in standard mode
- 1.All the requested parameters are obtainable from your network operator and/or services provider.
- 2. The phone number or access point name, the login and the password are automatically stored in the Con nection Manager (see Connection manager, page 51).
- 3. A profile name cannot be stored twice. If an error message is displayed please also check the profile names in the Connection profiles (see Connection manager, page 51).
- 4. Access to the connection settings may depend on the pre-programmation of the settings. The connection settings menu may not be available in some cases. These settings may be 'Locked' and not be user pro grammable.
- 5. You can request the activation of the security fea ture from the profiles list (Settings / Activate security).
- 6. Your service provider may require to have the secu rity context reset. Select Yes.
- Getting to the Options menu while online.
- Ending the online connection
- Creating bookmarks
- Using bookmarks
- Other site
- Receiving push messages
- Melodies download
- Customising your mobile
- Wallpaper
- Logo
- Appendix
- 1. use not conforming with the instruc tions for use or installation,
- 2. non observation of the technical and safety standards applicable in the country where the equipment is used,
- 3. improper maintenance of batteries and other sources of energy, and of the overall electric installation,
- 4. accidents or the consequences of theft, (of the vehicle), acts of vandal ism, lightning, fire, humidity, infiltra tion of liquids, atmospheric influences,
- 5. combination or integration of the equipment in hardware not supplied or not recommended by Alcatel, without express written consent for such,
- 6. modifications, alterations, or repairs carried out by parties not authorised by Alcatel, the dealer or the approved maintenance centre,
- 7. use of the equipment for a purpose other than that for which it was de signed,
- 8. normal wear,
- 9. deterioration caused by external caus es (RF interference produced by other equipment, fluctuations in mains volt age and/or voltages on telephone lines, etc),
- 10. modifications made to the equipment even if they are unavoidable due to changes in regulations and/or modifi cation of network parameters,
- 11. connection faults resulting from unsat isfactory radio transmission or caused by the absence of radio relay coverage.
- A
- B
- C
- D
- E
- F
- G
- I
- K
- L
- M
- N
- O
- P
- R
- S
- T
- V
- W
55
Internet/WAP™
Starting a WAP™ session:
If several WAP™ profiles are
stored, you need to select one be-
fore launching a session:
To launch a WAP™ session:
Getting to the Options menu
while online.
In the absence of Options
while online pressing during a
live connection shows the follow-
ing options menu:
Enter the requested parame-
ters. Select Save to store
the data.
Select Connection profiles
. Enter the requested infor-
mation (the Circuit access and
Packets access fields are linked
to the Connection manager).
Circuit and GPRS access names
and thus allow to pick one
from the displayed list - see
Connection manager,
page 51). Select Save to
store the data.
Select Push parameters
(please contact your service
provider to get the informa-
tion to be entered).
Your WAP™ profile is then
stored.
1.All the requested parameters are obtainable from
your network operator and/or services provider.
2. The phone number or access point name, the login
and the password are automatically stored in the Con-
nection Manager (see Connection manager, page 51).
3. A profile name cannot be stored twice. If an error
message is displayed please also check the profile
names in the Connection profiles (see Connection
manager, page 51).
4. Access to the connection settings may depend on
the pre-programmation of the settings. The connection
settings menu may not be available in some cases.
These settings may be 'Locked' and not be user pro-
grammable.
5. You can request the activation of the security fea-
ture from the profiles list (Settings / Activate security).
6. Your service provider may require to have the secu-
rity context reset. Select Yes.
Press . Select WAP™.
Select WAP™ profiles .
6
7
8
9
!
1
2
Scroll to the required profile
and choose one by selecting
OK (Selected is dis-
played).
Press . Select WAP™.
Select Home page .
The WAP™ connection is then
launched and the list of the
available site services is directly
displayed.
If the activated WAP™ profile
is not correctly set or if your
subscription does not allow
you to reach the selected
WAP™ site the Not available
then Connection failure mes-
sages are displayed.
To close the session, select Exit
and select Yes to vali-
date your choice or press
Options and select Close ses-
sion . To disconnect press
or press Options and
select Disconnect .
Item Action
Back
To go back to previous
page.
Home
page
To go to and reload the
home page.
Book-
marks
To provide immediate
access to the book-
marks. You can add a
new bookmark or select
an existing bookmark.
Reload
To reload the current
WAP
™ page.
3
1
2
3
