- Alcatel Owner's Manual Mobile Telephone One Touch 531
Table Of Contents
- English
- One TouchTM 531
- Introduction
- Using this guide
- Getting Started
- Network services
- Phone Book
- Messages
- Calls & Times
- Settings
- Key
- Action
- Feature
- Default setting
- Divert options
- Action
- Option
- Description
- Select
- Meaning
- Pass word
- Length
- Number of al lowed trials
- If blocked or forgot ten
- Phone lock code
- 4 digits
- Unlimited
- Return phone to manufac turer
- PIN
- 4-8 digits
- 3
- Un blocked by use of PUK code
- PIN2
- 4-8 digits
- 3
- Un blocked by use of PUK2
- PUK
- 8 digits
- 10
- Contact your service provider
- PUK2
- 8 digits
- 10
- Contact your service provider
- Call bar ring pass word
- 4 digits
- Defined by service provider
- Contact your service provider
- Office Tools
- Connectivity
- Games
- WAP™
- To enter and store the profile details via the Assistant
- To enter and store the profile details in standard mode
- 1.All the requested parameters are obtainable from your network operator and/or services provider.
- 2. The phone number or access point name, the login and the password are automatically stored in the Con nection Manager (see Connection manager, page 51).
- 3. A profile name cannot be stored twice. If an error message is displayed please also check the profile names in the Connection profiles (see Connection manager, page 51).
- 4. Access to the connection settings may depend on the pre-programmation of the settings. The connection settings menu may not be available in some cases. These settings may be 'Locked' and not be user pro grammable.
- 5. You can request the activation of the security fea ture from the profiles list (Settings / Activate security).
- 6. Your service provider may require to have the secu rity context reset. Select Yes.
- Getting to the Options menu while online.
- Ending the online connection
- Creating bookmarks
- Using bookmarks
- Other site
- Receiving push messages
- Melodies download
- Customising your mobile
- Wallpaper
- Logo
- Appendix
- 1. use not conforming with the instruc tions for use or installation,
- 2. non observation of the technical and safety standards applicable in the country where the equipment is used,
- 3. improper maintenance of batteries and other sources of energy, and of the overall electric installation,
- 4. accidents or the consequences of theft, (of the vehicle), acts of vandal ism, lightning, fire, humidity, infiltra tion of liquids, atmospheric influences,
- 5. combination or integration of the equipment in hardware not supplied or not recommended by Alcatel, without express written consent for such,
- 6. modifications, alterations, or repairs carried out by parties not authorised by Alcatel, the dealer or the approved maintenance centre,
- 7. use of the equipment for a purpose other than that for which it was de signed,
- 8. normal wear,
- 9. deterioration caused by external caus es (RF interference produced by other equipment, fluctuations in mains volt age and/or voltages on telephone lines, etc),
- 10. modifications made to the equipment even if they are unavoidable due to changes in regulations and/or modifi cation of network parameters,
- 11. connection faults resulting from unsat isfactory radio transmission or caused by the absence of radio relay coverage.
- A
- B
- C
- D
- E
- F
- G
- I
- K
- L
- M
- N
- O
- P
- R
- S
- T
- V
- W
54
WAP™
Your mobile allows WAP™(Wireless Appli-
cation Protocol) connections to access op-
erator and/or provided services (e.g. news,
sports, weather, travel buying, etc.).
To get a WAP™ connection please make
sure:
• your SIM card bears a Data sub-
scription
• all parameters are stored into the
mobile. These parameters may
have been set by your operator. If
not you have to enter them man-
ually.
Please contact your service provider to
check these elements and get the detailed
list of parameters to be entered.
Storing the connection set-
tings
The current date and time must be set be-
fore you enter any WAP™ connection set-
ting (see ’Setting the Date and Time’ on
the ’Getting started with your
One Touch™ 531 booklet).
The profile list can contain up to 10 WAP™
profiles. A profile is a WAP™ connection
list of parameters. Each profile allows ac-
cess to a specific WAP™ gateway.
To enter and store the profile
details via the Assistant
The Assistant feature allows easy entering
of the WAP™ parameters to access WAP™
servers. It displays the fields to be filled in
one after another.
To enter and store the profile
details in standard mode
You can only register profile details via the
standard mode if you have previously reg-
istered profiles in the Connection manager
menu (see Connection manager, page 51):
Press . Select WAP™.
Select WAP™ profiles .
Choose an empty profile ([...])
by selecting Assist .
1
2
3
Enter each parameter and vali-
date by selecting OK .
There are 6 screen levels to be
filled in. The requested infor-
mation depends on connec-
tion type.
If you want to set a WAP™
(circuit) connection, please fill
in the following fields:
1/6 Profile name
2/6 Gateway IP Address
3/6 Home page (URL
address): select List to get
and select one of the available
home page addresses or the
http:// and https:// root
addresses.
Select Circuit connection .
4/6 Phone number
5/6 Login (Identification)
6/6 Password (for access
control)
If you want to set a GPRS con-
nection, please fill in
the following fields:
1/6 Profile name,
2/6 Gateway IP Address,
3/6 Home page (URL
address)
Select Packets .
4/6 Access point name
5/6 Login (identification)
6/6 Password (for access
control)
Press . Select WAP™.
Select WAP™ profiles .
Choose an empty profile ([...])
by selecting OK .
Enter the profile name and
select OK .
Select Settings .
4
1
2
3
4
5
