- Alcatel Owner's Manual Mobile Telephone One Touch 531
Table Of Contents
- English
- One TouchTM 531
- Introduction
- Using this guide
- Getting Started
- Network services
- Phone Book
- Messages
- Calls & Times
- Settings
- Key
- Action
- Feature
- Default setting
- Divert options
- Action
- Option
- Description
- Select
- Meaning
- Pass word
- Length
- Number of al lowed trials
- If blocked or forgot ten
- Phone lock code
- 4 digits
- Unlimited
- Return phone to manufac turer
- PIN
- 4-8 digits
- 3
- Un blocked by use of PUK code
- PIN2
- 4-8 digits
- 3
- Un blocked by use of PUK2
- PUK
- 8 digits
- 10
- Contact your service provider
- PUK2
- 8 digits
- 10
- Contact your service provider
- Call bar ring pass word
- 4 digits
- Defined by service provider
- Contact your service provider
- Office Tools
- Connectivity
- Games
- WAP™
- To enter and store the profile details via the Assistant
- To enter and store the profile details in standard mode
- 1.All the requested parameters are obtainable from your network operator and/or services provider.
- 2. The phone number or access point name, the login and the password are automatically stored in the Con nection Manager (see Connection manager, page 51).
- 3. A profile name cannot be stored twice. If an error message is displayed please also check the profile names in the Connection profiles (see Connection manager, page 51).
- 4. Access to the connection settings may depend on the pre-programmation of the settings. The connection settings menu may not be available in some cases. These settings may be 'Locked' and not be user pro grammable.
- 5. You can request the activation of the security fea ture from the profiles list (Settings / Activate security).
- 6. Your service provider may require to have the secu rity context reset. Select Yes.
- Getting to the Options menu while online.
- Ending the online connection
- Creating bookmarks
- Using bookmarks
- Other site
- Receiving push messages
- Melodies download
- Customising your mobile
- Wallpaper
- Logo
- Appendix
- 1. use not conforming with the instruc tions for use or installation,
- 2. non observation of the technical and safety standards applicable in the country where the equipment is used,
- 3. improper maintenance of batteries and other sources of energy, and of the overall electric installation,
- 4. accidents or the consequences of theft, (of the vehicle), acts of vandal ism, lightning, fire, humidity, infiltra tion of liquids, atmospheric influences,
- 5. combination or integration of the equipment in hardware not supplied or not recommended by Alcatel, without express written consent for such,
- 6. modifications, alterations, or repairs carried out by parties not authorised by Alcatel, the dealer or the approved maintenance centre,
- 7. use of the equipment for a purpose other than that for which it was de signed,
- 8. normal wear,
- 9. deterioration caused by external caus es (RF interference produced by other equipment, fluctuations in mains volt age and/or voltages on telephone lines, etc),
- 10. modifications made to the equipment even if they are unavoidable due to changes in regulations and/or modifi cation of network parameters,
- 11. connection faults resulting from unsat isfactory radio transmission or caused by the absence of radio relay coverage.
- A
- B
- C
- D
- E
- F
- G
- I
- K
- L
- M
- N
- O
- P
- R
- S
- T
- V
- W
51
Connectivity
Connectivity
Infrared port
The infrared port allows to exchange data
between the mobile and other devices
(provided they have an infrared port).
Thanks to the infrared port you can down-
load or send files such as images for your
wallpaper (see Downloading images via
WAP™ and the infrared port, page 60),
send or receive Vcards,...
To initiate a transfer via the infrared port,
your mobile must be placed facing anoth-
er infrared port before port opening
starts.
Both ports can then be opened and syn-
chronised. The requested transfer can be
performed. Objects (e.g vCards) are trans-
ferred one by one.
Opening the infrared port
Opening the infrared port allows
to receive information via this
port.
Once opened, the infrared port
can be used for any kind of trans-
fer (data, fax, file transfer,...). The
infrared port is automatically
closed after a while.
To open the infrared port,
Items can then be received. When
an item is received, the idle screen
is masked by the new item recep-
tion status.
Closing the infrared port
Closing the infrared port closes all
infrared sessions (OBEX and Ir-
COMM sessions).
To close the infrared port:
Transferring a phonebook card
via the infrared port
You can transfer phonebook
cards via the infrared port:
Connection manager
The Connection manager service manages
and centralises circuit and packet connec-
tion profiles (see WAP™, page 54) for on-
line applications.
Creating a connection profile
Press . Select Connecti-
vity.
Select Infrared port .
Select Open . Confirmation
is displayed. is displayed
on top of the standby display
to confirm the port opening.
1
2
3
Press . Select Connecti-
vity.
Select Infrared port .
Select Close .
Place your mobile opposite
the other device infrared port.
Open the other device infra-
red port.
Select the card you wish to
transfer as explained in sec-
tion Viewing and calling pho-
nebook numbers, page 16.
Select Options . Select
Send by IrDA . The infra-
red port is opened and the
transfer is then performed.
Press . Select Connecti-
vity.
Select Connection
manager .
Select Connection
profiles .
Choose an empty profile
([...]) and select OK .
Choose GPRS connection or
Circuit connection and
select OK .
1
2
3
1
2
3
4
1
2
3
4
5
