- Alcatel Owner's Manual Mobile Telephone One Touch 531
Table Of Contents
- English
- One TouchTM 531
- Introduction
- Using this guide
- Getting Started
- Network services
- Phone Book
- Messages
- Calls & Times
- Settings
- Key
- Action
- Feature
- Default setting
- Divert options
- Action
- Option
- Description
- Select
- Meaning
- Pass word
- Length
- Number of al lowed trials
- If blocked or forgot ten
- Phone lock code
- 4 digits
- Unlimited
- Return phone to manufac turer
- PIN
- 4-8 digits
- 3
- Un blocked by use of PUK code
- PIN2
- 4-8 digits
- 3
- Un blocked by use of PUK2
- PUK
- 8 digits
- 10
- Contact your service provider
- PUK2
- 8 digits
- 10
- Contact your service provider
- Call bar ring pass word
- 4 digits
- Defined by service provider
- Contact your service provider
- Office Tools
- Connectivity
- Games
- WAP™
- To enter and store the profile details via the Assistant
- To enter and store the profile details in standard mode
- 1.All the requested parameters are obtainable from your network operator and/or services provider.
- 2. The phone number or access point name, the login and the password are automatically stored in the Con nection Manager (see Connection manager, page 51).
- 3. A profile name cannot be stored twice. If an error message is displayed please also check the profile names in the Connection profiles (see Connection manager, page 51).
- 4. Access to the connection settings may depend on the pre-programmation of the settings. The connection settings menu may not be available in some cases. These settings may be 'Locked' and not be user pro grammable.
- 5. You can request the activation of the security fea ture from the profiles list (Settings / Activate security).
- 6. Your service provider may require to have the secu rity context reset. Select Yes.
- Getting to the Options menu while online.
- Ending the online connection
- Creating bookmarks
- Using bookmarks
- Other site
- Receiving push messages
- Melodies download
- Customising your mobile
- Wallpaper
- Logo
- Appendix
- 1. use not conforming with the instruc tions for use or installation,
- 2. non observation of the technical and safety standards applicable in the country where the equipment is used,
- 3. improper maintenance of batteries and other sources of energy, and of the overall electric installation,
- 4. accidents or the consequences of theft, (of the vehicle), acts of vandal ism, lightning, fire, humidity, infiltra tion of liquids, atmospheric influences,
- 5. combination or integration of the equipment in hardware not supplied or not recommended by Alcatel, without express written consent for such,
- 6. modifications, alterations, or repairs carried out by parties not authorised by Alcatel, the dealer or the approved maintenance centre,
- 7. use of the equipment for a purpose other than that for which it was de signed,
- 8. normal wear,
- 9. deterioration caused by external caus es (RF interference produced by other equipment, fluctuations in mains volt age and/or voltages on telephone lines, etc),
- 10. modifications made to the equipment even if they are unavoidable due to changes in regulations and/or modifi cation of network parameters,
- 11. connection faults resulting from unsat isfactory radio transmission or caused by the absence of radio relay coverage.
- A
- B
- C
- D
- E
- F
- G
- I
- K
- L
- M
- N
- O
- P
- R
- S
- T
- V
- W
29
Calls & Times
To set call cost type to units:
Setting the credit limit (sub-
scription dependent)
You may also be able to set a
credit limit to your calls. When the
credit limit is reached no more
chargeable outgoing or incoming
call is allowed. You can however
still make emergency calls.
The PIN2 code is needed to set the
credit limit.
Show costs
Call costs - resetting all costs to
zero
To reset all call costs to zero:
Alternate line service - selecting
line 2 (subscription dependent)
Some operators support the use
of a second line. You may then
have two mobile phone numbers
(e.g. a business line plus a person-
al line). To use them you need to
select the line to be used.
Enter the unit cost (e.g.: 0.15
Euro per minute).
Press OK to validate.
Press . Select Calls &
Times.
Select Call costs .
Select Display cost type .
Select Units .
When the cost type is set to units the credit limit and
the remaining credit are shown in units.
Press . Select Calls &
Times.
Select Call costs .
Select Credit limit . The
display shows the current set
credit limit.
Select Edit . Enter your PIN
2 code and press OK .
Enter the credit limit (use
to type a decimal point for
curencies). Press OK to
validate.
When a credit limit is set the selection from the 'Credit
limit' display is Edit or Set no limit.
Press . Select Calls &
Times.
Select Call costs .
Select Show .
7
1
2
3
4
!
1
2
3
4
5
!
1
2
3
Use or to display the
Last Call and All Calls
or show the Remaining
credits.
The remaining credit is shown in either units or cur-
rency as set by Cost Type menu above.
Press . Select Calls &
Times.
Select Call costs .
Select Reset .
Select Yes .
Enter the PIN 2 number and
press OK .
Press . Select Calls &
Times.
Select Line selection.
The current line selection is
displayed.
Use or to scroll to the
required line. Press OK to
validate.
1. The Line selection sub-menu may not be available
on your mobile. Please contact your service provider to
get further details on this service.
2. Line 1 and Line 2 can be named (Office and Home
for instance). Refer to the Own Number menu (see
Own number(s) display, page 17 for details). Whiche-
ver line is selected to send calls, incoming calls can
still be received on either line.
4
!
1
2
3
4
1
2
3
!
