- Alcatel Owner's Manual Mobile Telephone One Touch 531
Table Of Contents
- English
- One TouchTM 531
- Introduction
- Using this guide
- Getting Started
- Network services
- Phone Book
- Messages
- Calls & Times
- Settings
- Key
- Action
- Feature
- Default setting
- Divert options
- Action
- Option
- Description
- Select
- Meaning
- Pass word
- Length
- Number of al lowed trials
- If blocked or forgot ten
- Phone lock code
- 4 digits
- Unlimited
- Return phone to manufac turer
- PIN
- 4-8 digits
- 3
- Un blocked by use of PUK code
- PIN2
- 4-8 digits
- 3
- Un blocked by use of PUK2
- PUK
- 8 digits
- 10
- Contact your service provider
- PUK2
- 8 digits
- 10
- Contact your service provider
- Call bar ring pass word
- 4 digits
- Defined by service provider
- Contact your service provider
- Office Tools
- Connectivity
- Games
- WAP™
- To enter and store the profile details via the Assistant
- To enter and store the profile details in standard mode
- 1.All the requested parameters are obtainable from your network operator and/or services provider.
- 2. The phone number or access point name, the login and the password are automatically stored in the Con nection Manager (see Connection manager, page 51).
- 3. A profile name cannot be stored twice. If an error message is displayed please also check the profile names in the Connection profiles (see Connection manager, page 51).
- 4. Access to the connection settings may depend on the pre-programmation of the settings. The connection settings menu may not be available in some cases. These settings may be 'Locked' and not be user pro grammable.
- 5. You can request the activation of the security fea ture from the profiles list (Settings / Activate security).
- 6. Your service provider may require to have the secu rity context reset. Select Yes.
- Getting to the Options menu while online.
- Ending the online connection
- Creating bookmarks
- Using bookmarks
- Other site
- Receiving push messages
- Melodies download
- Customising your mobile
- Wallpaper
- Logo
- Appendix
- 1. use not conforming with the instruc tions for use or installation,
- 2. non observation of the technical and safety standards applicable in the country where the equipment is used,
- 3. improper maintenance of batteries and other sources of energy, and of the overall electric installation,
- 4. accidents or the consequences of theft, (of the vehicle), acts of vandal ism, lightning, fire, humidity, infiltra tion of liquids, atmospheric influences,
- 5. combination or integration of the equipment in hardware not supplied or not recommended by Alcatel, without express written consent for such,
- 6. modifications, alterations, or repairs carried out by parties not authorised by Alcatel, the dealer or the approved maintenance centre,
- 7. use of the equipment for a purpose other than that for which it was de signed,
- 8. normal wear,
- 9. deterioration caused by external caus es (RF interference produced by other equipment, fluctuations in mains volt age and/or voltages on telephone lines, etc),
- 10. modifications made to the equipment even if they are unavoidable due to changes in regulations and/or modifi cation of network parameters,
- 11. connection faults resulting from unsat isfactory radio transmission or caused by the absence of radio relay coverage.
- A
- B
- C
- D
- E
- F
- G
- I
- K
- L
- M
- N
- O
- P
- R
- S
- T
- V
- W
27
Calls & Times
Calls & Times
Access the Calls & Times menu to check
the details of individual incoming and out-
going calls, the duration of the latest call
or the total call time for all sent and re-
ceived calls.
Calls log
This feature stores details (identity, time
and date and call duration) on the latest
10 numbers dialled, the latest 10 unan-
swered calls and the latest 10 received
calls. The calls log are common to Line 1
and Line 2.
The latest dialled or received number is
displayed first. For unanswered and re-
ceived calls the caller’s name is displayed if
it is registered in one of the phonebooks (if
not the phone number is displayed). If
your subscription does not bear Caller Line
Identification (CLI) or if the caller has with
held their number Unknown number is
displayed.
Press to call the selected number.
Press Options to get to the following
menu:
Use or to select the required option
and follow the displayed instructions.
Call timers
The Call timers stores time information
on all voice, Internet, Modem and GPRS
calls for Line 1 and Line 2.
The Details sub-menu stores time in-
formation on calls made and received via
the home network and while roaming (na-
tional and international networks).
The call type and the accumulated times of
outgoing and incoming calls are dis-
played.
Selecting Details displays information
on roaming and international calls etc.
Press . Select Calls &
Times.
Select Calls log .
Select Last dial, Unan-
swered or Received .
Use or to scroll through
the calls list.
Item Action
Store
To store the number into
a phonebook.
Delete
To delete the entry.
Delete all
To delete all the entries.
Edit
To edit the displayed
number.
Details
To view the name,
number, time and date
and call duration of the
selected number.
1
2
3
4
Call
To call the selected
number.
Send
SMS
To send an SMS message
to the selected phone
number.
Press the key from the stand by display to get
direct access to the 10 last dialled numbers.
Press . Select Calls &
Times.
Select Call timers .
Select Show .
If the call timers were reset
(see Call timer - reset,
page 28) the date of the lat-
est counter reset is displayed.
Use or to view all the
timer information.
If Line 2 is active too 'All Calls' for Line 1 and Line 2
will be displayed separately.
!
1
2
3
4
!
